    Jewelry Lab Stereo Optical Microscope With 360°Rotatable Head , CE A23.0903-STL1

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A23.0903-STL1
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Jewelry Lab Stereo Optical Microscope With 360°Rotatable Head , CE A23.0903-STL1


    Jewelry Lab Stereo Optical Microscope With 360°Rotatable Head , CE A23.0903


    Description:


    --0.67~4.5x Zoom Lens, with WF10x/22mm Eyepiece,
    --Total Optical Magnification 6.7~45x
    --Universal Pole Stand To Observe Specimen From Any Direction or Angle.
    --Fully Coated Optical System, Sharp & Clear Image


    Specifications:


    A23.0903-STL1 Zoom Stereo Microscope, 0.67x-4.5x Specification

    Head

    Brinocular, 45° Inclined, 360° Rotatable, +/-5° Diopter Adjustable,

    Interpupillary Adjustment 54~75mm

    Zoom Range

    0.67~4.5x

    Zoom Ratio

    1:6.5

    Eyepiece

    WF10x/22mm, Both with Eye-cup

    Magnification

    6.7~45x, Up to 2~225x with Auxiliary Lens

    Working Distance

    100mm, With Standard 1x Lens. Up to 26~287mm With Auxiliary Lens

    Stand

    Universal Pole Stand STL1, To Observe Specimen From Any Direction or Angle.
    Vertical Post Height 380mm, Pillar Size Dia.32mm,
    Focusing Post Height 104mm, Pillar Size Dia.32mm
    Horizontal Adjustment Range 235mm
    Stage Size 230*230*40mm

    Illumination

    No Light Source

    A23.0903-STL1 Zoom Stereo Microscope, 0.67x-4.5x Optional Accessories

    Eyepiece

    WF15x/15mm

    A51.0923-15

    WF20x/10mm

    A51.0923-20

    WF25x/9mm

    A51.0923-25

    Auxiliary Lens

    0.3x, W.D. 287mm

    A52.0928-03

    0.4x, W.D. 217mm

    A52.0928-04

    0.5x, W.D. 177mm

    A52.0928-05

    0.75x, W.D. 117mm

    A52.0928-75

    1.5x, W.D. 47mm

    A52.0928-15

    2.0x, W.D. 26mm

    A52.0928-20
