    Comparison Polarizing Light Microscope Transmitted Light Microscopes CE A15.1019

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A15.1019
    Price : Negotiation
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Comparison Polarizing Light Microscope Transmitted Light Microscopes CE A15.1019


    Comparison Polarizing Light Microscope Transmitted Light Microscopes CE A15.1019


    Specifications:


    A15.1019 Polarizing Microscope Specification
    A
    B
    Optical SystemInfinite optical system
    Head
    Seidentopf trinocular head inclined at 30°, interpupilary48-75mm
    Eyepiece
    Plan eyepiece EW 10x/22
    Plan eyepiece with scale of crosshair, Plan eyepiece with cross, Plan eyepiece with gridding
    Strainfree plan achromatic objective
    5x/0.12/∞/- WD 15.5mm
    10x/0.25/∞/- WD 10.0mm
    20x/0.4/∞/-0 WD 5.8mm
    50x/0.75/∞/0 WD 0.32mm
    100x/0.8/∞/0 WD 2mm
    40x/0.65/∞/0.17 WD 0.54mm
    -
    100x/1.25/∞/0.17 WD 0.13mm
    -
    Nosepiece
    Backward quintuple nosepiece, center adjustable
    Analyzer360° dial rotation minimum scale reading: 0.1° (Vernier scale)
    Conoscopic ObservationSwitch between orthoscopic and conoscopic observation, Bertrand lens position adjustable
    Optical Compensator

    --λSlip(first class red)
    --1/4λSlip
    --Quartz wedge

    Condenser

    Strain-free swing condenser NA0.9/0.25
    Polarizing Rotatable
    Stage
    Diameter Φ170mm, Center adjustable, 360° scale, Minimum divison 1°, Minimum reading 6 by means of vernier scale ,45° Click stop knob
    FocusingCoaxial coarse & fine adjustment, Range 32mm, Fine division 0.001mm, Coarse stroke 37.7mm per rotation, Fine stroke 0.1mm per rotation
    Polarizer
    Transmitted: 360° Rotatable 0° position adjustable
    -
    Reflected: Fixed
    FilterBlue filter Φ45mm
    -
    Illumination
    Transmitted light: 24V/100W Halogen lamp, Brightness adjustable
    -
    Reflected light: 24V/100W Halogen lamp, Brightness adjustable
    Optional Accessories
    Item No.
    Attachable StageMoving range 30mmx40mmA54.1002-T
    FilterND6 Neutral density filterA5F.1005-6
    ND25 Neutral density filterA5F.1005-25
    AttachmentCCD adapter 1xA55.1002-10
    CCD adapter 0.5x
    A55.1002-05

    Description:


    The polarized light microscope is designed to observe and photograph specimens that are visible primarily due to their optically anisotropic character. Polarized light microscopes have a high degree of sensitivity and can be utilized for both quantitative and qualitative studies targeted at a wide range of anisotropic specimens. Qualitative polarizing microscopy is very popular in practice, with numerous volumes dedicated to the subject. In contrast, the quantitative aspects of polarized light microscopy, which is primarily employed in crystallography, represent a far more difficult subject that is usually restricted to geologists, mineralogists, and chemists.
