    Transmission Polarizing Light Microscope For Silicon Wafers A15.1122

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A15.1122
    Price : Negotiation
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Transmission Polarizing Light Microscope For Silicon Wafers A15.1122


    Transmission Polarizing Light Microscope For Silicon Wafers A15.1122


    Description:


    A15.1122 transmission polarization microscope is one of the most modern designed instruments for metallurgy, geology and minerals areas and is in common use in altitude academy. Recent year, with the development of optics technology, polarization microscope, as optics instrument, whose the range of application becomes wider and wider. A15.1122 transmission polarization microscope is collocated gypsum (λ), mica(1/4λ) sample, quartz wedge, attachable mechanical stage and any other parts. It is a set of new product that has maturity function and good quality.


    Specifications:


    A15.1122 Polarizing Microscope Specification
    -A
    -B
    Head
    Sliding Binocular,45°inclined,52mm-74mm
    -
    Sliding Trinocular,45°inclined,52mm-74mm
    -
    EyepieceWide Field WF10X/18mm
    10X Gridding Eyepiece
    10X Eyepiece with Reticule
    Achromatic Objective4X
    10X
    25X
    40X(S)
    63X(S)
    Focus System
    Coaxial Coarse and Fine Focusing with Rack and Pinion Mechanism; Fine Focusing Scale Value 0.002mm
    CondenserSwing Type N.A.1.25 Abbe Condenser with Iris Diaphragm&Filter
    Stage
    Round Revolving Stage,Stage Size: Φ160mm,Moving Range:360°
    CollectorHigh brightness Light Collector
    Light SourceHalogen Bulb 6V/30W,AC 85V-230V ,Adjustble Brightness
    Optional Accessories
    EyepieceWF16X
    WF20X
    P16X
