Specification

A16.2701 Fluorescent Microscope

B2

B4

T2

T4

Optical System

UCIS infinity independent achromatic optical system

Head

Seidentopf binocular head 30° inclined, rotatable 360°,

interpupillary distance 52-75mm, Diopter Adjustable

●

●

Seidentopf trinocular head 30° inclined, rotatable 360°,

interpupillary distance 52-75mm, Diopter Adjustable

●

●

Magnification

40x - 1000x

Eyepiece

WF10x/20mm, high eyepoint up to 21mm,

Objective

Infinity plan achromatic objectives 4x, 10x, 40x(s) and 100x (s/oil)

Focus System

Low positioned, coaxial coarse & fine focusing system

with tension adjustment and up-limited, coarse 14mm/rot,

fine 0.1mm/rot, minimum reading 1μm on left-side fine knob,

moving range 20mm

Nosepiece

Quadruple, reversed type with positive click stops

Kohler Illumination

with field diaphragm

Condenser

Abbe condenser N.A. 1.25 with iris diaphragm and

phase contrast socket

Stage

Right hand controls, brightness adjustable, low position,

mechanical stage,156mm x 138mm, movement range 76mm x 54mm

Flourescent Attachment

Epi-reflected fluorescence illumination system: 100W mercury

lamp house and 100W power supply unit

Excitation Filter

B,G

●

●

B,G,UV,V

●

●

Light Source

250V/5A Φ5X20 fuse

6V20W Halogen lamp

250x/3.15A Φ5x20 fuse

Other

Blue Φ38

Immersion Oil

Dust cover

Power cord

Optional Accessories

Item No.

Head

Binocular Head,30° Inclined, 360° Rotatable, Interpupillary

Distance 48-75m, ±5 Diopter Adjustment

A53.2702-2A

Trinocular Head,30° Inclined, 360° Rotatable, Interpupillary

Distance 48-75mm, ±5 Diopter Adjustment

A53.2704-2A

Eyepiece

Plan WF10x/22mm, high eyepoint up to 21mm

A51.2701-10C

Plan WF16x/13mm,high eyepoint

A51.2701-1613

Plan WF10x/20mm, reticule eyepiece

A51.2703-10A

Objective

Infinity plan achromatic objectives 4x

A52.2706-04C

Infinity plan achromatic objectives 20x(s)

A52.2706-20C

Infinity plan achromatic objectives 60x(s)

A52.2706-60C

Nosepiece

Quadruple, reversed type with positive click stops

A54.2704-B

Condenser

Swing out condenser

A56.2701-30A

Stage

Upgrade to mechanical stage 185x177mm platform, moving

range 75x50mm, low positioned x-y coaxial control knob

(right or left hand),two slides holder

A54.2701-2C

Illumination

6V/30W Halogen Illumination

A56.2703-30

6V30W Osram Halogen Bulb

A56.2703-30C

100W Osram Mercury Lamp

A5F.2716-I

LED Flourescent Attachment

5W LED lamp house

Power supply unit for 5W LED lamp house

Excitation Filter B/G/UV/V

Filter Φ38

Green

A56.2706-G

Yellow

A56.2706-Y

Frosted Glass

A56.2706-F

Adapter

1.0x C-Mount

A55.2701-10

0.25x C-Mount

A55.2701-25
