    40X 100x Wide Field Polarizing Light Microscope Halogen Lamp A15.0202

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A15.0202
    Price : Negotiation
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    40X 100x Wide Field Polarizing Light Microscope Halogen Lamp A15.0202


    Description:


    --Equipped with strain-free plan achromatic objectives and wide field eyepiece
    --Coaxial coarse/fine focus system with tension adjustable and limit stopper, minimum division of fine focusing: 2μm
    --Take-down style polarizer, 360°rotatable, have 0,90,180,270 four scale, located down the aperture diaphragm
    --Impellent style analyzer, 360°rotatable, push in / out from optical path conveniently
    --Collector composed with field diaphragm and filter seat
    --Revolving round stage, 360°part scale and graduated in 1°increments, minimum resolution 6' when using vernier scale, center adjustable and with tightener
    --Illumination with 6V20W halogen lamp, adjustable brightness
    --Trinocular and digital & video camera can be chosen



    Specifications:


    A15.0202 Polarizing Microscope Specification
    A1
    A2
    B1
    B2
    EyepiecesWF10X/18mm Wide Field
    Division eyepiece 10X (Ф18mm) 0.10mm/div
    Strain-free Plan Achromatic Objectives
    281 series
    PL 4X/0.10
    -
    -
    -
    PL 10X/0.25
    -
    -
    -
    PL 40X/0.65 (spring)
    -
    -
    -
    PL 100X/1.25(Spring,oil)
    -
    -
    -
    Strain-free Infinity Plan Achromatic
    282 series
    PL 4X/0.10
    -
    -
    -
    PL 10X/0.25
    -
    -
    -
    PL 40X/0.65 (spring)
    -
    -
    -
    PL 100X/1.25(Spring,oil)
    -
    -
    -
    Strain-free Plan Achromatic
    (no cover glass)
    284 series
    PLL4X/0.10
    -
    -
    -
    PLL10X/0.25
    -
    -
    -
    PLL 40X/0.6
    -
    -
    -
    PLL 60X/0.75 (spring)
    -
    -
    -
    Strain-free Infinity Plan Achromatic (no cover glass)
    286 series
    PL 5X/0.12
    -
    -
    -
    PL 10X/0.25
    -
    -
    -
    PL20X/0.4
    -
    -
    -
    PL 40X/0.6 (spring)
    -
    -
    -
    HeadTrinocular head,revolved (inclination of 30 °),100% image light for photography capable
    Intermediate Attachment360° rotatable with scale and minimum vernier
    Bertrand lens, impellent style, center adjustable
    λ compensator
    λ 1/4 compensator
    Quarts wedge compensator
    Focus SystemCoaxial coarse/fine system, with tension adjustable and limit stopper, minimum division of fine focusing 2um
    NosepieceQuadruple, frontward ball bearing inner locating
    Stage

    Rotatable stage, diameter |μ150mm, 360° graduated (in 1° increasements), minimum retardation resolution 6' center adjustable and with tightener

    Abbe Condenser

    N.A. 1.25 rack & Pinion adjustable

    Polarizer360°rotatable, with four scale is 0°, 90°,180°,270°
    FilterFrosted filter
    Blue filter
    CollectorFor illumination with halogen lamp (with field diaphragm)
    Illumination UnitWith polarizer, 6V20w, halogen lamp, adjustable brightness
    Optional Accessories
    Item No.
    EyepieceWF16x/11mm wide field
    A51.0203-16A
    Eyepiece TubeBinocular, inclination of 30°
    A53.0204-9
    ObjectiveStrain-free plan achromatic PL 5x/0.12
    A5P.0205-5
    Strain-free plan achromatic PL 20x/0.40
    A5P.0205-20
    Strain-free plan achromatic PL 60x/0.85(Spring)
    A5P.0205-60
    Infinity strain-free plan achromatic PL 4X/0.10
    A5P.0207-04
    Infinity strain-free plan achromatic PL 20X/0.40
    A5P.0207-20
    NosepieceQuintuple, frontward ball bearing inner locating
    A54.0203-4
    FilterGreen filter
    A56.0209-2
    Yellow filter
    A56.0209-3
    CCD Adapter
    0.4X
    A55.0202-01
    0.5X
    A55.0202-04
    1X
    A55.0202-02
    0.5X with dividing 0.1mm/Div
    A55.0202-03
    Photo Adapter
    2.5X/4X Change over photograph adapter with 10X viewing eyepiece
    A55.0201-1
    4X Focusing photograph adapter
    A55.0201-2
    MD Adapter
    A55.0201-3
    PK Adapter
    A55.0201-4
    DC Adapter
    Digital camera adapter CANON (A610,A620,A630,A640)
    A55.0204-01
