1000x White Inverted Metallurgical Optical Microscope Research A13.2601

    Buy cheap 1000x White Inverted Metallurgical Optical Microscope Research A13.2601 from wholesalers

    Buy cheap 1000x White Inverted Metallurgical Optical Microscope Research A13.2601 from wholesalers
    • Buy cheap 1000x White Inverted Metallurgical Optical Microscope Research A13.2601 from wholesalers
    • Buy cheap 1000x White Inverted Metallurgical Optical Microscope Research A13.2601 from wholesalers

    1000x White Inverted Metallurgical Optical Microscope Research A13.2601

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A13.2601
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    1000x White Inverted Metallurgical Optical Microscope Research A13.2601


    1000x White Inverted Metallurgical Optical Microscope Research A13.2601


    Description:


    A13.2601 Metallurgical Microscope, new design with high quality optical system, supplying clear image, is good to be used in laboratory research work or school education field.

    --Plan Metallurgical Objective
    --LWD Plan Metallurgical Objective Optional
    --Polarzing Set of Polarizer & Analyzer
    --Mechanical, size 180x165mm, moving range 50x40mm, 3 Stage Plate Available


    Specifications:


    Specification
    A13.2601 Metallurgical Microscope
    HeadTrinocular, inclinded 45°, interpupillary distance 50-75mm, light distribution 20:80
    EyepieceWF10X/18mm
    WF12.5X/14mm
    WF10x/20mm with micrometer 0.1mm/Div, 1pc
    Objective

    Plan Metallurgical Objective
    10x/0.25, W.D.=8.8mm
    20x/0.35(S), W.D.=1.59mm
    40x/0.65(S), W.D.=0.73mm
    100x/1.25(O,S), W.D.=0.69mm

    NosepieceQuadruple nosepiece
    FocusingCoaxial coarse and fine focusing knob
    StageMechanical, size 180x165mm, moving range 50x40mm
    Stage plate 1 Φ10
    Stage plate 2 Φ20
    PolarizingPolarizer Slide
    Analyer Slide
    FilterBlue, Green, Grey, White
    Light source6V 30W halogen lamp with brightness control, spare lamp 2 pcs, spare fuse 2 pcs
    Input Voltage 100-240V
    Packing1pc/carton, size 59x59x33cm, G/N weight 15/11 Kgs
    Optional Accessories
    Item No.
    EyepieceHuygens 5x/20mmA51.2601-05
    WF10x/20mmA51.2602-1020
    WF16x/13mmA51.2602-1613A
    WF10x/18mm, with micrometer 0.1m/DivA51.2605-10
    ObjectivePlan Metallurgical Objective2.5x/0.07A5M.2630-2.5
    4x/0.10,W.D=17.5mmA5M.2630-4
    LWD Plan Metallurgical ObjectivePLL40x/0.60, W.D.=3.64mmA5M.2631-40P
    PLL50x/0.70, W.D.=3.01mmA5M.2631-50P
    PLL80x/0.80, W.D.=1.08mmA5M.2631-80P
    Stage PlateStage plate 3 Φ40A54.2603-40
    AdapterCCD Adapter 0.6xA55.2601-M06
    CCD Adapter 1.0xA55.2601-M10
    Digital Camera AdapterFor OLYMPUS digital cameraA55.2620
    For CANON digital cameraA55.2621
    Digital SLR Camera AdapterFor NIKON SLR digital cameraA55.2622-N
    For SONY SLR digital cameraA55.2622-S
    For Canon SLR digital cameraA55.2622-C
