Specification

A13.2704 Inverted Metallurgical Microscope

Optical System

UCIS infinity independent achromatic optical system

Frame

One-piece construction from arm to base

Head

Seidentopf trinocular head, 30° inclined, interpupillary distance

52-75mm, diopter adjustable

Eyepiece

WF10x/20mm, plan, high eyepoint up to 21mm,

WF10x/18mm, high eyepoint up to 21mm,, reticule eyepiece, diopter adjustable

Objective

Infinity LWD plan achromatic objective 10x

Infinity LWD plan achromatic objective 20x(s)

Infinity LWD plan achromatic objective 50x(s)

Infinity LWD plan achromatic objective 80x(s)

Focus System

Coaxial coarse and fine focus mechanism with markings.

fine focus sensitivity 1μm, coarse range 14mm

Nosepiece

Quintuple, reversed type with positive click stops

Stage

Low position, mechanical stage, size 180x150mm, moving range 80x50mm.

Drop specimen holder(φ110)

Specimen holder

Illumination

Metallurgical reflected illuminator

100W halogen lamp house,

Electrical parts for 12V 50W halogen lamp

12V50W Halogen bulb (Osram)

250V/5A Φ5X20 Fuse

Power supply 110-240V 50/60Hz

Filter (Φ32)

Blue filter

Green filter

Yellow filter

Polarizing Attachment

Analyzer

Polarizer

Other

Allen screw driver 1.5mm

Allen screw driver 2mm

Allen screw driver 3mm

Metallurgical micrometer(1/100mm)

Dust cover

Power cord

Optional Accessories

Item No.

Head

Seidentopf binocular head, 30° inclined, interpupillary distance

52-75mm, diopter adjustable

A53.2702-3

Seidentopf binocular head, 30° inclined, interpupillary distance

52-75mm, diopter adjustable (For FOV 22mm)

A53.2702-2B

Seidentopf trinocular head, 30° inclined, interpupillary distance

52-75mm, diopter adjustable (For FOV 22mm)

A53.2704-2A

Eyepiece

WF10x/22mm plan eyepiece, high eyepoint

A51.2701-10C

WF10x/20mm reticule eyepiece, high eyepoint, diopter adjustable

A51.2703-10A1

Objective

Infinity plan achromatic objective 5x

A52.2706-05A

Infinity plan achromatic objective 100x

A52.2706-100A

Filter

White Filter (Φ32)

A56.2706-W1

Adapter

1.0x C-Mount

A55.2701-10

0.5x C-Mount

A55.2701-05

0.25x C-Mount (suitable to 1/3" CCD)

A55.2701-25

Digital camera adapter (need to know camera brand)

A55.2702-2

Micrometer

Optical Metallurgical Micrometer

A58.2701
