    Laboratory Biology Epi-Fluorescence Microscope 100X - 400X A16.0206

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE
    Model Number : A160206
    Price : Negotiation
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Laboratory Biology Epi-Fluorescence Microscope 100X - 400X A16.0206

    Laboratory Epi-Fluorescence Microscope 100X - 400X A160206


    Description:


    Fluorescence Microscope is to irradiate the specimen with a desired and specific band of wavelengths, and then to separate the much weaker emitted fluorescence from the excitation light. Epi-fluorescence illumination is the overwhelming choice of techniques in modern microscopy. The technique of fluorescence microscopy has become an essential tool in biology and the biomedical sciences, as well as in materials science due to attributes that are not readily available in other contrast modes with traditional optical microscopy.



    Specifications:

    A160206 Inverted Fluoresent Microscope
    Head
    Inclination 45 Degree interpupillary distance is 53~75mm.
    Eyepiece
    Wide field WF10X(field number:Φ22mm)
    Centering telescope
    Objective
    Infinity Plan Achromatic Objective, PLL 10x/0.25, WD 4.3mm, Cover Glass 1.2mm
    Infinity Plan Achromatic Objective, PLL 20x/0.40, WD 8.0mm, Cover Glass 1.2mm
    Infinity Plan Achromatic Objective, PLL 40x/0.60, WD 3.5mm, Cover Glass 1.2mm
    Phase Contrast Objective PLL10x/0.25 PHP2, WD 4.3mm, Cover Glass 1.2mm
    Phase Contrast Objective PLL20x/0.40 PHP2, WD 8.0mm, Cover Glass 1.2mm.
    Phase Contrast Objective PLL40x/0.60 PHP2, WD 3.5mm, Cover Glass 1.2mm
    Epi-fluorescent
    Illumination System
    Power supply unit, 110V or 230V can be selected.
    100W/DC Mercury lamp is 100W/DC
    Fluorescent filters
    Group
    Type
    Wavelength of excitation light
    Wavelength of emitted light
    UV+V
    Ultraviolet light (UV)
    330nm~400nm
    425nm
    Violet light (V)
    395nm~415nm
    455nm
    B+G
    Blue light (B)
    420nm~485nm
    515nm
    Green light (G)
    460nm~550nm
    590nm
    Focus System
    Coaxial coarse/fine focus, with tension adjustable and up stop, minimum division of fine focusing is 2um
    Nosepiece
    Quintuple nosepiece
    Stage
    Fixed stage overall size is 227mmX208mm
    Glass rotundity stage overall size Dia:118mm
    Mechanical moving device, moving range is 77mm (longitudinal)X114mm (transverse)
    Culture dish holder 1
    Inside locating slot size: 86mm (W)X129.5mm (L), optional with a circular culture dish Ф87.5mm
    Culture dish holder 2
    Inside locating slot size: 34mm (W)X77.5mm (L), optional with a circular culture dish Ф68.5mm
    Culture dish holder 3
    Inside locating slot size:57mm (W)X82mm (L)
    Transmitted illumination
    system
    Turnplate phase contrast condenser, working distance is 55mm
    6V30W halogen, brightness enable control
    Frosted glass and blue , green filter
    Optional Accessory
    Item No.
    Eyepiece
    10XDividing eyepiece(field number:¦µ22mm) 0.10mm/Div
    A51.0205-G10B
    Objective
    Infinity plan achromatic objective PL 5X/0.12 W.D26.1
    A52.0206-4
    Nosepiece
    Sextupe (Backward ball bearing inner locating)
    A54.0204
    CCD adapter
    0.4X
    A55.0202-01
    0.5X
    A55.0202-04
    1X
    A55.0202-02
    0.5Xwith dividing 0.1mm/Div
    A55.0202-03
    DC Aadapter
    CANON(EF), NIKON(F)
    A55.0204-01
