A16.0901

A16.0901-CCD

Optical System

Infinity Color Corrected Optical System

Head

Trinocular Head , Gemel Viewing Head, 45 Degree Inclined,
Interpupilary Distance 54-75mm, Spliting Ratio 100:0 or 0:100

Eyepiece

PL10x/22mm, High Eyepoint, Wide Field

Nosepiece

Revolving Quintuple Nosepiece

Objective

Long Working Distance Infinity Plan
Achromatic Objectives
LWDPL10X/0.25, W.D.=7.94mm
LWDPL20X/0.40, W.D.=7.66mm
LWDPL40X/0.60, W.D.=3.71mm
Long Working Distance Infinity Plan Phase
Contrast Objectives
LWDPH20X/0.40, W.D.=7.66mm .
.
.
.
.

Long Working Distance Infinity Plan
Fluorescent Objectives
LWDPLF4X/0.13, W.D.=18.52mm
LWDPLF10X/0.30, W.D.=7.11mm
Long Working Distance Infinity Plan
Semi-Apochrmatic Objectives
LWDPLFPH20X/0.45, W.D.=5.91mm
LWDPLFPH40X/0.65, W.D.=1.61mm
Long Working Distance Infinity Plan
Phase Contrast Objectives
LWDPH10X/0.25, W.D.=7.94mm

Stage

Fixed Stage Size 250*160mm, Slider Clips
--Glass Plate
--Metal Plate
--Petri Dish Holder, Dia.35mm
.
.
.

Fixed Stage Size: 250*160mm,

Slider Clips,

with Extension Plate and Coaxial
Moveable Stage, Moving Range

120*78mm
--Glass Plate
--Metal Plate with Kidney Slot
--Petri Dish Holder, Dia.35mm
--Slide Holder, Dia.54mm,26.

5x76.4mm
--Teraseki Holder, Dia.65mm,

56x81.5mm

Focusing

Coaxial Coarse & Fine Focusing System, Coarse Adjustment
Range 9mm, Fine Adjustment Precision 0.002mm,with Tension
Adjustment, with Safty Stop

Condenser

N.A.0.3 Kohler Illumination Condenser, with Phase Adjustable
Slide Plate, Long Working Distance 72mm. The Whole Set
Can Be Rotated Down

Phase Contrast

Phase Contrast Plug-board for 10x-40x, Center Adjustable
Centering Telescope Dia. 30mm

Filter

Dia.45mm Green Interference Filter
Dia.45mm Color Temperature Change Filter
Attenuation Plate, Transmission 25%

Reflected Fluorescence
illumination System

--Reflected Kohler Illumination with Iris Field Diaphragm,
Centering Adjustable

--U-LH100HG Mercury Lamp House, Filament Center and
Focal Distance Adjustable, with Mirror, Mirror Center and
Focal Distance Adjustable

--U1-RFLT100 Digital Power Control Box, Wide Voltage Range 90-240V AC

--Imported OSRAM 100W DC Mercury Bulb

Centered Objective For Mecury Bulb

Band-pass Fluorescent Filter B, G

Band-pass Fluorescent Filter B, G, UV

30ND25 Attenuation Plate

CCD Adapter

0.67x CCD Adapter, for 2/3" CCD Camera

CCD Camera

1.4M, 2/3" CCD, USB 2.0 Cold CCD
Scientific Research Class Cold CCD,

Light

Critical Illumination, With Iris Aperture, Halogen 6V30W, Pre-centered,
Intensity Adjustable

Power

Wide Voltage 90-240V
