    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE
    Model Number : A59.2208
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208


    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208

    A59.2208-E USB2.0 CMOS Digital Camera

    A59.2208-E adopt SONY Exmor CMOS sensor as the image-picking device and USB2.0 is used as the data transfer interface.

    A59.2208-E hardware resolutions range from 1.2M to 8.3M and come with the integrated CNC aluminum alloy compact housing.

    A59.2208-E comes with advanced video & image processing application ToupView; Providing Windows/Linux/macOS/Android multiple platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc);

    The A59.2208-E can be widely used in bright field light environment and microscope image capture and analysis with higher frame rate.

    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208
    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208
    Order CodeSensor & Size(mm)Pixel(μm)G Sensitivity Dark SignalFPS/ResolutionBinningExposure
    8.3MPA8.3M/IMX274©
    1/2.5”(6.22x3.50)
    1.62x1.62236mv with 1/30s
    0.1mv with 1/30s
    4@3840x2160
    16@1920x1080
    1x1
    2x2
    0.244ms~15s
    6.6MPA6.6M/IMX326©
    1/2.9”(4.98x3.50)
    1.62x1.62236mv with 1/30s
    0.1mv with 1/30s
    5@3072x2160
    6@2592x1944
    6@3072x1728
    7@2160x2160
    1x1
    1x1
    1x1
    1x1
    0.244ms~15s
    5.3MPA5.3M/IMX178©
    1/1.9“ (7.37x4.15)
    2.4x2.4425mv with 1/30s
    0.15mv with 1/30s
    5.5@3072 x1728
    35@1280x720
    1x1
    2x2
    0.105ms~15s
    5.0MPA5.0M/IMX335©
    1/2.8“ (5.18x3.89)
    2.0x2.0505mv with 1/30s
    0.13mv with 1/30s
    6.4@2592 x1944
    26.7@1296x972
    1x1
    2x2
    0.1ms~15s
    3.1MPA3.1M/IMX123©
    1/2.8“ (5.12x3.84)
    2.5x2.5600mv with 1/30s
    0.15mv with 1/30s
    11.5@2048x1536
    18.3@1920x1080
    18.1@1600x1200
    29.5@1024x768
    1x1
    1x1
    1x1
    2x2
    0.105ms~15s
    2.0MPA2.0M/IMX290©
    1/2.8“(5.56x3.13)
    2.9 x2.91300mv with 1/30s
    0.15mv with 1/30s
    17@1920x10801x10.105ms~15s
    1.2MPA1.2M/IMX224©
    1/3“(4.80x3.60)
    3.75 x3.752040mv with 1/30s
    0.15mv with 1/30s
    27@1280x960
    54@640x480
    1x1
    2x2
    0.105ms~15s
    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208
    Other Specification
    Spectral Range380-650nm (with IR-cut Filter)
    White BalanceROI White Balance/ Manual Temp Tint Adjustment/NA for Monochromatic Sensor
    Color TechniqueUltra-Fine Color Engine/NA for Monochromatic Sensor
    Capture/Control SDKWindows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc)
    ADC8 Bit
    Recording SystemStill Picture and Movie
    Cooling System*Natural
    Operating Environment
    Operating Temperature(in Centidegree)-10~ 50
    Storage Temperature(in Centidegree)-20~ 60
    Operating Humidity30~80%RH
    Storage Humidity10~60%RH
    Power SupplyDC 5V over PC USB Port
    Software Environment
    Operating SystemMicrosoft® Windows® XP / Vista / 7 / 8 /10 /11 (32 & 64 bit)
    OSx(Mac OS X)
    Linux
    PC RequirementsCPU: Equal to Intel Core2 2.8GHz or Higher
    Memory: 2GB or More
    USB Port: USB2.0 Port
    Display: 17” or Larger
    CD-ROM
    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208
    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208
    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208
    Standard Camera Packing List
    ACarton L:52cm W:32cm H:33cm (20pcs, 12~17Kg/ carton), not shown in the photo
    BGift box L:15cm W:15cm H:10cm (0.5~0.55Kg/ box)
    COne ECMOS series camera
    DHigh-speed USB2.0 A male to B male gold-plated connectors cable /2.0m
    ECD (Driver & utilities software, Ø12cm)
    Optional Accessory
    FAdjustable lens adapterC-mount to Dia.23.2mm eyepiece tube
    (Please choose 1 of them for your microscope)
    108001/AMA037
    108002/AMA050
    108003/AMA075
      C-mount to Dia.31.75mm eyepiece tube
    (Please choose 1 of them for your telescope)
    108008/ATA037
    108009/ATA050
    108010/ATA075
    GFixed lens adapterC-mount to Dia.23.2mm eyepiece tube
    (Please choose 1 of them for your microscope)
    108005/FMA037
    108006/FMA050
    108007/FMA075
      C-Mount to Dia.31.75mm eyepiece tube
    (Please choose 1 of them for your telescope)
    108011/FTA037
    108012/FTA050
    108013/FTA075
    Note: For F and G optional items, please specify your Camera type(C-mount, microscope camera or telescope camera) , ToupTek engineer will help you to determine the right microscope or telescope camera adapter for your application;
    H108015(Dia.23.2mm to 30.0mm ring)/Adapter rings for 30mm eyepiece tube
    I108016(Dia.23.2mm to 30.5mm ring)/ Adapter rings for 30.5mm eyepiece tube
    J108017(Dia.23.2mm to 31.75mm Ring)/ Adapter rings for 31.75mm eyepiece tube
    KCalibration kit106011/TS-M1(X=0.01mm/100Div.);
    106012/TS-M2(X,Y=0.01mm/100Div.);106012/TS-M2(X,Y=0.01mm/100Div.);
    106013/TS-M7(X=0.01mm/100Div., 0.10mm/100Div.)
    USB 2.0 Digital Camera Microscope Microscope Accessories A59.2208
