    SONY USB3.0 CMOS Digital Camera Microscope 2560 * 1920 A59.2212

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE
    Model Number : A59.2212
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    SONY USB3.0 CMOS Digital Camera Microscope 2560 * 1920 A59.2212


    Description:

    --Color Aptina CCD Sensor
    --USB3.0 C-Mount CMOS Camera
    --Square Housing:68 X 68 X 45mm
    --Support Microsoft Windows XP / Vista / 7 /8 (32 & 64 bit)
    --Support OS X (MAC OS X) and Linux
    --Support Native C/C++, C#, Directshow, Twain, Labview
    --With Standard C-mount, Eyepiece Tube, And Ring Dia.30mm, Dia.30.5mmiew



    Specifications:

    Pixel
    C300K
    C1.45M
    C5.0M
    C5.2M
    Senser Size
    1/3.0" CCD
    2/3" CCD
    2/3" CCD
    2/3" CCD
    Image Pickup DeviceSONY ICX618ALA CCD(Mono)SONY ICX285AQ CCD(Color)SONY ICX282AQ
    CCD(Color)
    SONY ICX655AQ CCD(Color)
    Scan Mode
    Progressive
    Interlaced
    Progressive
    Imaging Area
    3.6mm(H)*
    2.7mm(V)
    10.0mm(H) x 9.3mm(V)
    9.74mm(H) x 7.96mm(V)9.93mm(H) x 8.70mm(V)
    Output
    USB3.0
    Max.Resolution
    640*480
    1360*1024
    2560*1920
    Pixel Size
    5.6x 5.6μm
    6.45 x 6.45μm
    3.4μm x 3.4μm3.45μm x 3.45μm
    G Sensitivity
    1200mV with 1/30s Accumulation
    1240mV with 1/30s Accumulation260mV with 1/30s Accumulation420mV with 1/30s Accumulation
    Dynamic Range
    70dB
    A/D Converter
    12-bit Parallel, 8-Bit R.G.B to PC
    SN Ratio
    62dB
    Binning
    1*1
    1*1, 2*2
    1 x 1
    Exposure
    0.06ms~40s
    ROI Auto & Manual
    0.12ms~240s, ROI Auto & Manual
    0.20ms~105ms, ROI Auto & Manual0.22ms~60s, ROI Auto & Manual
    Peak Quantum Efficiency65%35%60%
    Readout Noise4.5 e (r.m.s) @ gain high /5.6 e (r.m.s) @ gain lowN/AN/AN/A
    Extinction Ratio1 : 2000 @1ms exposure timeN/AN/AN/A
    Smear-110dBN/AN/AN/A

    General Specification

    Spectral Range380-650nm (with IR-Filter)
    White balanceROI White Balance/ Manual Temp-Tint Adjustment
    Color Rendering TechniqueUltra Fine Color Engine
    Video Format
    & Frame Rate
    N/A
    Capture/Control APINative C/C++, C#, Directshow, Twain, Labview
    Recording SystemStill Picture and Movie
    Cooling SystemNatural
    Operating Environment
    TemperatureOperating Temp.:-10~50℃
    Storage Temperature-20℃~ 60℃
    HumidityOperating Humidity:30%~80%RH
    Storage Humidity:10~60%RH
    Power SupplyDC 5V from PC USB port
    Software Environment
    Operating SystemMicrosoft Windows XP / Vista / 7 (32 & 64 bit)
    OS X (Mac OS X), Linux
    PC RequirementsCPU: Equal to Intel Core2 2.8GHz or Higher
    Memory: 2GB or More
    USB port: USB2.0 High-speed Port
    Display: 17" or Larger
    CD-ROM
