    2048 Pixels Camera Microscope Accessories With TCD1304 ILX554 A59.2216

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A59.2216
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    2048 Pixels Camera Microscope Accessories With TCD1304 ILX554 A59.2216


    Specifications:


    Pixel
    1
    2
    3
    Senser Model
    TCD1304
    (1D Toshiba CCD)
    ILX554
    (1D Sony CCD)
    ILX511
    (1D Sony CCD)
    Max.Resolution
    3648 Pixels
    2048 Pixels
    Senser Size
    29.184mm
    28mm
    Pixel Size
    8μm x 200μm
    14μm x 56μm
    14μm x 200μm
    Sensitivity
    200 V/lx.s with Daylight Fluorescent Lamp
    240 V/lx.s with Uniform Intensity Illumination,
    3500 V/lx.s (600nm LED)
    200 V/lx.s with Uniform Intensity Illumination,
    1800 V/lx.s (600nm LED)
    Spectral Range
    300-1000nm
    A/D Converter
    16-bit to PC
    Output Rate
    1.0MHZ
    ExposureRange
    3.8-4000ms
    2-4000ms
    External Trigger
    Supported
    Capture/Control API
    SDK and Example Code
    Capture Mode
    Single Camera Multiple Instance and Multiple Cameras Supported
    Host Interface
    USB2.0

    General Specification

    Operating SystemMicrosoft Windows XP / Vista / 7 (32 & 64 bit)
    CPU: Equal to Intel Core2 2.8GHz or Higher
    Memory:2GB or More
    USBPort:USB2.0 High-speed Port
    Operating Temp.-30~70℃
    Storage Temperature-40~85℃
    Operating Humidity30%~80%RH
    Storage Humidity10%~60%RH
    Power SupplyOver USB Port
    Package Box140mmx140mmx80mm, 0.5Kgs
    Color Rendering TechniqueUltra FineTM Color Engine
    Capture ModeStill Picture and Video
    RemarksActual frame rates on your computer depend on the hardware and operating system used

    Optional Accessory

    Lens MountM42
