    Microscope Digital Cameras Microscope Accessories A59.2215

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A59.2215
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Microscope Digital Cameras Microscope Accessories A59.2215



    Specifications:

    Pixel
    1
    2
    3
    4
    5
    Sensor Size (Diagonal)
    2/3“ (Diagonal 11mm)
    2/3“
    (Diagonal 11mm)
    1/2“ (Diagonal 7.959mm)
    1/2“ (Diagonal 7.959mm)
    2/3“
    (Diagonal 11.016mm)
    Image Pickup DeviceSONY ICX285AQ CCD(Color)SONY ICX285AK CCD(Mono)SONY ICX205AK CCD(Color)
    SONY ICX205AL CCD(Mono)
    SONY ICX655AQA CCD(Color)
    Scan ModeProgressive
    Max.Resolution1360 x 1024 (Approx. 1,400,000 Pixels)2448 x 2050 (Approx. 5,018,000 Pixels)
    Pixel Size6.45μm x 6.45μm4.65μm x 4.65μm3.45μm x 3.45μm
    Imaging Area10.2mm(H) x 8.3mm(V)7.60mm(H) x 6.20mm(V)9.93mm(H) x 8.70mm(V)
    G Sensitivity1240mV with 1/30s Accumulation400mV with 1/30s Accumulation420mV with 1/30s Accumulation
    Dynamic Range70dB
    A/D Converter
    12-bit Parallel, 8-bit R.G.B to PC
    12-bit Parallel, 8-bit PC12-bit Parallel, 8-bit R.G.B to PC12-bit Parallel, 8-bit to PC12-bit Parallel, 8-bit R.G.B to PC
    SN Ratio62dB
    Spectral Range
    380-650nm (with IR-filter)
    Video Format & Frame Rate15fps @1360 x 1024(Multiple Speed Level)4.3fps @2448 x 2050, 10.5fps @960 x 720 (Multiple Speed Level)
    Binning
    1 x 1
    Exposure0.12ms~240s, ROI Auto & Manual0.22ms~60s, ROI Auto & Manual
    White balanceROI White Balance/ Manual Temp-Tint Adjustment
    Color Rendering TechniqueUltra Fine Color Engine
    Peak Quantum Efficiency65%35%60%
    Readout NoiseN/A
    Extinction RatioN/A
    SmearN/A
    Capture/Control APINative C/C++, C#, Directshow, Twain, Labview
    Recording SystemStill Picture and Movie
    Cooling System*TE-Cooled CCD - 20 °C below Ambient Temperature

    General Specification

    Operating System

    Microsoft Windows XP / Vista / 7 (32 & 64 bit)
    OS X(Mac OS X), Linux
    CPU: Equal to Intel Core2 2.8GHz or Higher
    Memory:2GB or More
    USBPort:USB2.0 High-speed Port
    Display: 17" or Larger
    CD-ROM

    Operating Temp.-10~50℃
    Storage Temperature-20~60℃
    Operating Humidity30%~80%RH
    Storage Humidity10%~60%RH
    Power SupplyDC 5V over PC USB Port
    Color Rendering TechniqueUltra FineTM Color Engine
    Capture ModeStill Picture and Video
    RemarksActual frame rates on your computer depend on the hardware and operating system used
