    Achromatic Phase Contrast Microscope A19.2702

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A19.2702
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Achromatic Phase Contrast Microscope A19.2702


    Specifications:


    Specification
    A19.2702 Phase Contrast Microscope
    B
    T
    Optical SystemUCIS Infinity independent achromatic optical system
    Head
    Seidentopf binocular head 30° inclined, 360 ° rotatable interpupillary distance 52-75mm
    Seidentopf trinocular head 30° inclined, 360 ° rotatable interpupillary distance 52-75mm
    Eyepiece
    WF10X/20mm, high eye-point
    Centering Telescope
    Objective
    Infinity Achromatic objective 4x
    Infinity Achromatic phase-contrast objective 10x
    Infinity Achromatic phase-contrast objective 40x(S)
    Infinity Achromatic phase-contrast objective 100(S/Oil)
    Focus System
    Coaxial coarse and fine focus mechanism with markings. Fine focus sensitivity 0.001mm
    Nosepiece
    Inward quadruple nosepiece
    CondenserN.A. 1.25 Phase contrast condenser, center adjustable
    Stage
    Mechanical stage with double layers, 156mmx138mm, movement range 76mmx 52mm
    Light source
    6V 20W halogen illumination, brightness adjustable
    6V 30W halogen illumination, brightness adjustable
    3W LED, brightness adjustable
