    LED Illumination Digital Optical Microscope


    LED Illumination USB Digital Optical Microscope 1000X A32.0601-9000DPL


    Description:

    The digital video zoom microscope combines the tradtional optical technology and digital imaging technology and offers high quality video images. It can solve the problems generated by using a traditional microscope that requires a strict environment. Equipped with high performance Nickel hydrogen rechargeable battery, it can be used for longer inspection time in fieldwork.

    With powerful functions of real-time micro-photography, video recording and measurement, on-site high-speed image acquisition, digital image input to PC for inspection, image storage, video recording, measurement at micron-level and image output can be realized. It is a good substitute for a traditional optical magnifier, stereo microscpe, comparing microscope, video measurement system and micro-photographing instrument. When used in long-distance scene evidence identification, the images of on-site evidence samples can be captured, inspected, compared and measured, and the on-site scene can enter the micro-world instantly.


    Specifications:


    A32.0601-9000DPL Digital Video Zoom Specification
    Zoom Body of Zoom Range
    0.7x-4.5x
    Zoom Ratio
    1:6.5
    Total Magnification
    4.7x-1000x
    Semi-plan Achromatic Objective
    0.3x, 0.5x, 0.75x, 1.5x and 2x (optional)
    High-Power Objective Lens
    5x and 10x (optional)
    Image Sensor
    1.3M pixel 1/2" color CMOS
    Pixel Size
    5.2um x 5.2um
    Spectrum Response
    400nm-1000nm
    Scanning Type
    Progressive scanning
    Exposal Type
    ERS
    Resolution
    1280x1024
    Transmission Rate
    16f/s@1280*1024, 30f/s@640*480, 30f/s@320*240
    White Balance
    Automatic operation supported
    Exposal Control
    Manual opertion supported
    Image Output
    USB2.0, 480Mb/s
    FunctionImage capture, video recording and measuring function
    Laser PointerWave length: 650nm
    Working Temperature0-50 degree
    Minimum System Requirement

    Windows 2000, XP and Vista Operation System

    PIII 800 CPU or above
    256MB Memory or above
    64MB video memory or above
    USB2.0 interfaces
    1024*768 resolution monitor or above
    StandTripod
    Tilt ball head
    Super mag slider

    Extension bar

    Laptop tray
    Connector of tilt ball head
    IlluminationFiber optia illuminator(Input 120v(max.)60hz)
    Fiber optia illuminator(Input 240v(max.)50hz)
    Dual pipe light guide
    Optional Accessories
    Objectives
    0.3x, Semi-Plan, Outer Dia.30mm, W.D.331mmA52.0626-03
    0.5x, Semi-Plan, Outer Dia.30mm, W.D.198mmA52.0626-05
    0.75x, Semi-Plan, Outer Dia.30mm, W.D.131mmA52.0626-75
    1.5x, Semi-Plan, Outer Dia.30mm, W.D.63mmA52.0626-15
    2.0x, Semi-Plan, Outer Dia.30mm, W.D.46mmA52.0626-20
    5x Infinity corrected long working distance objectiveA52.0627-5
    10x Infinity corrected long working distance objectiveA52.0627-10
    Illumination Accessories
    Iris DiaphragmA56.0606
    LED side lightA56.0607
    Polarizing MicroscopePolarizerA5P.0602
    Rechargeable Battery
    4.8V 2200mA/h, Nickel hydrogen batteryA50.0602
    Battery Charger, Input Voltage 100-240V 50/60Hz, Output Voltage 6.0-6.5V, Current 250-350mAA50.0602-R
