A12.0905 Laboratory Biological Microscope | B | T | BI | TI |
Magnification | 40x~1000x |
Head | Compensation Free Binocular Head, 30° Inclined,360° Rotatable | o |
|
|
|
Compensation Free Trinocular Head, 30° Inclined,360° Rotatable |
| o |
|
|
Compensation Free Binocular Head, 30° Inclined,360° Rotatable, +/-5° Diopter Adjustable, Infinity System |
|
| o |
|
Compensation Free Trinocular Head, 30° Inclined,360° Rotatable, +/-5° Diopter Adjustable, Infinity System |
|
|
| o |
Eyepiece | PL10x/18mm, Wide Field, High Eyepoint | o | o |
|
|
PL10x/20mm, Wide Field, High Eyepoint |
|
| o | o |
Nosepiece | Quadruple Nosepiece |
Objective | Plan Achromatic
4x/0.10, 10x/0.25, 40xs/0.65, 100xs/1.25(Oil) | o | o |
|
|
InfinityPlan Achromatic
4x/0.10, 10x/0.25, 40xs/0.65, 100xs/1.25(Oil) |
|
| o | o |
Stage | Double Layer Mechanical Stage, 150*140mm, Mvoing Range 50*76mm, Precision 0.1mm, Double Slide Holder |
Focusing | Low Position Coaxial Coarse & Fine Focusing. Coarse Focusing Range 28mm, Fine Focusing Scale 0.002mm, With Tension Adjustment, With Up Limit |
Condenser | N.A.1.25 Abbe Condenser, Iris Diaphargm, With Filter Holder |
Filter | Blue, Dia.45mm |
Light Source | Critcal Illumination, 6V/20W Halogen Lamp |
Power | 90~240V Wide Range Voltage |
A12.0905 Laboratory Biological Microscope Optional Accessories |
Eyepiece | WF10x/18mm with Reticle | A51.0905-1018PR |
WF10x/20mm with Reticle | A51.0905-1020R |
WF10x/18mm with Pointer | A51.0906-1018P |
WF10x/20mm with Pointer | A51.0906-1020P |
WF15x/13mm, High Eyepoint | A51.0902-1513 |
WF20x/10mm High Eyepoint | A51.0902-2010 |
Objective | Plan Achromatic 25xs/0.40 | A52.0903-25 |
InfinityPlan Achromatic 20xs/0.50 | A52.0906-20 |
Adapter | 0.5x C-Mount, For 1/2" CCD, Focus Adjustable | A55.0924-05 |
0.35x C-Mount, For 1/3" CCD, Focus Adjustable | A55.0924-35 |
Photo Adapter, With Photo Eyepiece 3.2x, With PK or MD Mount | A55.0901-1 |
Filter | Yellow, Dia.45mm | A56.0935-XYY |
Green, Dia.45mm | A56.0935-XYG |
Netural, Dia.45mm | A56.0935-XYF |
Light Source | Kohler Illumination, 6V/20W Halogen Lamp | A56.0905-LK |
Critcal Illumination, 3W LED Halogen Lamp | A56.0905-LED |
Kohler Illumination, 3W LED Halogen Lamp | A56.0905-LEDK |
Polarizing | Polarizer Dia..32mm, Put on Collector | A5P.0911-P |
Analyzer Slide, Insert To Hole On Nosepiece | A5P.0911-A |
Rotatable Working Stage | A5P.0916-RW |
Dark Field | Dark Field Board Slide, For 4x~10x Objective, Critical Illumination | A5D.0915-1 |
Dark Field Board Slide, For 20x~40x Objective, Critical Illumination | A5D.0915-2 |
Dark Field Board Slide, For 4x~40x Objective, Kohler Illumination | A5D.0915-K |
Phase Contrast | Centering Telescope, Dia.23.2mm | A5C.0910-232 |
5 Holes Turret Phase Contrast Condenser, N.A. 1.25 | A5C.0912-PCC |
Phase Contrast Slide, For 10x, 40x | A5C.0915-P1 |
Phase Contrast Slide, For 20x, 100x | A5C.0915-P2 |
Phase Contrast Plan Achromatic Objective 10x | A5C.0931-10 |
Phase Contrast Plan Achromatic Objective 20x | A5C.0931-20 |
Phase Contrast Plan Achromatic Objective 40x | A5C.0931-40 |
Phase Contrast Plan Achromatic Objective 100x | A5C.0931-100 |
InfinityPhase Contrast | Centering Telescope, Dia.23.2mm | A5C.0910-232 |
5 Holes Turret Phase Contrast Condenser, N.A. 1.25 | A5C.0912-PCCI |
Phase Contrast Slide, For 10x, 40x Infinity | A5C.0915-IP1 |
Phase Contrast Slide, For 20x, 100x Infinity | A5C.0915-IP2 |
Phase Contrast InfinityPlan Achromatic Objective 10x | A5C.0935-10 |
Phase Contrast InfinityPlan Achromatic Objective 20x | A5C.0935-20 |
Phase Contrast InfinityPlan Achromatic Objective 40x | A5C.0935-40 |
Phase Contrast InfinityPlan Achromatic Objective 100x | A5C.0935-100 |
