    Home White Binocular Head Biological Compound Microscope 1000X A12.0203


    White Binocular Biological Compound Microscope 1000X A12.0203


    Description:


    Compound Optical Microscope, is a type of microscope which uses visible light and a system of lenses to magnify images of small samples. We have a wide range for usage in laboratory, university, institute, or schools, for used extensively in microelectronics, nanophysics, biotechnology, pharmaceutics research, mineralogy and microbiology.


    Specifications:


    Specification
    A12.0203-A1
    A12.0203-A2
    A12.0203-B1
    A12.0203-B2
    Eyepiece
    WF10X(Φ20mm)
    Objective
    Plan 4X/0.10
    Plan 4X/0.10
    Plan 10X/0.25
    Plan 10X/0.25
    Plan 20X/0.40
    Plan 40X/0.65(Spring)
    Plan 40X/0.65(Spring)
    Plan 100X/1.25(Spring, oil)
    Plan 100X/1.25(Spring, oil)
    Head
    Binocular
    Trinocular
    Binocular
    Trinocular
    Focus System
    Coaxial coarse/fine focus system, Minimum division of fine focusing: 2um
    With tensional adjustable and up stop,
    Nosepiece
    Quadruple
    backward ball bearing inner locating
    Quintuple
    backward ball bearing inner locating
    Stage
    Double layer mechanical, size 210x140mm, moving range 75x50mm
    Condenser
    Abbe N.A.1.25 Rack & pinion adjustment
    Filter
    Blue filter
    Frosted filter
    Collector
    For halogen lamp
    Light source
    6V 20W halogen lamp with brightness control
    Optional Accessories
    Item No.
    EyepieceWide field WF16x/11mmA51.0203-16A
    Divding 10x/20mm, 0.1mm/DivA51.0205-10
    FilterGreen filterA56.0209-02
    Yellow filter
    A56.0209-03
    CondenserDark field, dryA5D.0210-D
    Dark field, immersion
    A5D.0210-I
    Phase Contrast AttachmentCentering telescopeA5C.0212-1
    Objective, Phase contrast plan 10x/0.25 PHP
    A5C.0230-P10
    Objective, Phase contrast plan 20x/0.40 PHP(Spring)A5C.0230-P20
    Objective, Phase contrast plan 40x/0.65 PHP(Spring)A5C.0230-P40
    Objective, Phase contrast plan 100x/1.25 PHP (Spring,oil)A5C.0230-P100
    PH-I Turnplate phase contrast condenserA5C.0210-1
    PH-II Turnplate phase contrast condenserA5C.0210-4
    Flashboard phase contrast setA5C.0210-2
    Pull board phase contrast set
    A5C.0210-3
    Infinity Optical SystemBinocular head inclination of 30°A53.0203-111
    Trinocular head inclination of 30°
    A53.0208-1
    Centering telescopeA5C.0212-2
    Objective, infinity plan achromatic 4x/0.10A52.0205-04
    Objective, infinity plan achromatic 10x/0.25A52.0205-10
    Objective, infinity plan achromatic 20x/0.25A52.0205-20
    Objective, infinity plan achromatic 40x/0.65(Spring)A52.0205-40
    Objective, infinity plan achromatic 100x/1.25(Spring, oil)A52.0205-100
    Objective, infinity phase contrast plan 10x/0.25 PHPA5C.0233-10
    Objective, infinity phase contrast plan 20x/0.40 PHP (Spring)A5C.0233-20
    Objective, infinity phase contrast plan 40x/0.65 PHP (Spring)A5C.0233-40
    Objective, infinity phase contrast plan 100x/1.25 PHP (Spring, oil)
    A5C.0233-100
    CCD adapter0.4xA55.0202-01
    0.5xA55.0202-04
    1xA55.0202-02
    0.5x with dividing 0.1mm/DivA55.0202-03
    Digital Camera Adapter
    For Canon EF ditigal SLR camera adapter
    A55.0204-02
    Photo Adapter
    2.5x/4x change over photograph attachment with 10x viewing eypiece
    A55.0201-01
    4x focusing photograph attachmentA55.0201-02
    MD adapterA55.0201-03
    PK adapter
    A55.0201-04
    Polarizing AttachmentPolarizer 360° rotatableA5P.0210-1
    AnalyzerA5P.0211-1
