A12.0907-A Laboratory Microscope

Head

Binocular, 30° Inclined, Interpupillary Distance 54-75mm

Eyepiece

PL10x/18mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree

Objective

Infinity Plan Achromatic 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25

Nosepiece

Backward Quadruple

Focusing

Low Position Coaxial Coarse & Fine Focusing Knob, with Safty Limitation and Tension
Adjustment Ring. Coarse Range 25mm, Fine Precision 0.002mm

Working Stage

Double Layer Mechanical Stage 140*132mm, Moving Range 76*50mm, Precision 0.1mm

Condenser

Kohler N.A. 1.25, with Socket for Phase Contrast and Dark Field Slides, Center Fixed

Light Source

3W LED, Intensity Adjustable, Center Fixed

Power

90~240V Wide Range Power Supply

A12.0907-A Laboratory Microscope Optional Accessories

Head

Trinocular, 30° Inclined, Interpupillary Distance 54-75mm

A53.0906-T30R

Eyepiece

PL10x/20mm, Wide Field, High Eye Point,
Diopter Adjustable +/-5 Degree

A51.0904-1020T

Objective

Infinity Plan Achromatic 20x/0.50

A52.0906-20

Nosepiece

Backward Quintuple

A54.0930-BS5

Filter

Blue, Dia.45

A56.0935-XYB

Yellow,Dia.45

A56.0935-XYY

Green, Dia.45

A56.0935-XYG

Netural, Dia.45

A56.0935-XYF

Adapter

C-Mount 1.0x, Focus Adjustable

A55.0925-1

C-Mount 0.5x, Focus Adjustable , for 1/2 CCD

A55.0925-1/2

C-Mount 0.35x, Focus Adjustable, for 1/3 CCD

A55.0925-1/3

Photo Adapter with PK or MD mount, with 3.2x Photo Eyepiece

A55.0901-1

Dark Field

Dark Field Slide, for 4x~40x Objective

A5D.0915-K

Polarizing

Polarizer

A5P.0911-P

Analyser

A5P.0911-A

Phase Contrast

Centering Telescope, Dia.23.2mm

A5C.0910-232

Phase Contrast Slide, for 10x, 40x Infinity Objective

A5C.0915-IP1

Phase Contrast Slide, for 20x,100x Infinity Objective

A5C.0916-IP2

Infinity Plan Phase Contrast Objective 10x/0.25, W.D.=4.70mm

A5C.0937-10

Infinity Plan Phase Contrast Objective 20x/0.50, W.D.=1.75mm

A5C.0937-20

Infinity Plan Phase Contrast Objective 40x/0.65, W.D.=0.72mm

A5C.0937-40

Infinity Plan Phase Contrast Objective 100x/1.25, W.D.=0.15mm

A5C.0937-100
