A12.0902 Laboratory Biological Microscope

A

B

C

D

Magnification

40x~1600x

Head

Monocular Head, 45° Inclined, 360° Rotatable

o

Sliding Binocular Head, 45° Inclined, 360° Rotatable

o

Compensation Free Binocular Head, 30° Inclined, 360° Rotatable

o

Compensation Free Trinocular Head, 30° Inclined, 360° Rotatable

o

Eyepiece

Wide Field WF10x/18mm, High Eyepoint

o

o

o

Wide Field WF16x/14mm, High Eyepoint

o

Nosepiece

Quadruple Nosepiece

Objective

Achromatic 4x/0.10, 10x/0.25, 40xs/0.65

o

Achromatic 4x/0.10, 10x/0.25, 40xs/0.65, 100xs/1.25(Oil)

o

Plan Achromatic 4x/0.10, 10x/0.25, 40xs/0.65, 100xs/1.25(Oil)

o

o

Stage

Single Layer Plain Stage, 136*120mm, With Slide Clip

o

Double Layer Mechanical Stage, 132*140mm, Mvoing Range
50*76mm, Precision 0.1mm

o

o

o

Focusing

Low Position Coaxial Coarse & Fine Focusing. Fine Focusing
Scale 0.002mm, With Tension Adjustment, With Up Limit

Condenser

5 Holes Disc Condenser, N.A.0.65

o

N.A.1.25 Abbe Condenser, Iris Diaphargm, With Filter Holder

o

o

o

Filter

Blue, Yellow, Green

Light Source

12V15W Halogen Light, 110V/220V

A12.0902 Laboratory Biological Microscope Optional Accessories

Eyepiece

WF10x/18mm with Reticle

A51.0905-1018R

WF10x/18mm with Pointer

A51.0906-1018

WF15x/13mm, High Eyepoint

A51.0902-1513

WF20x/10mm, High Eyepoint

A51.0902-2010

Objective

Achromatic 60xs/0.85

A52.0901-60

Plan Achromatic 25xs/0.40

A52.0903-25

Adapter

1.0x C-Mount

A55.0921-10

0.5x C-Mount, For 1/2" CCD, Focus Adjustable

A55.0921-05

0.35x C-Mount, For 1/3" CCD, Focus Adjustable

A55.0921-35
