    LED Trinocular Stereo Microscope For Clinic Dental A23.0901-BL3

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A23.0901-BL3
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    LED Trinocular Stereo Microscope For Clinic Dental A23.0901-BL3


    LED Trinocular Stereo Microscope For Clinic Dental A23.0901-BL3


    Description:


    --0.7~4.5x Zoom Lens, with WF10x/20mm Eyepiece,
    --Total Optical Magnification 7~45x
    --Uo & Bottom High Brightness LED Light Source, Separatly Controlled
    --Big Fan Pole Stand
    --110~240V Wide Range Voltage


    Specifications:


    A23.0901-BL3 Zoom Stereo Microscope Specification

    B

    T

    Head

    Binocular Head, 45° inclined, 360°Rotatable, ±5 Diopter Adjustable,

    Interpupillary Adjustment 54-75mm

    o

    Trinocular Head, 45° inclined, 360°Rotatable, ±5 Diopter Adjustable,

    Interpupillary Adjustment 54-75mm

    o

    Eyepiece

    WF10x/20mm, High Eyepoint

    Zoom Lens

    0.7~4.5x

    Zoom Ratio

    1:6.5

    Magnification

    7x-45x, Up to 3.5x-180x With Optional Eyepieces and Auxiliary Objectives

    Working Distance

    100mm, With Auxiliary Objectives 30~165mm

    Field of View

    1~95.2mm

    Light Source

    Uo & Bottom High Brightness LED Light Source, Separatly Controlled

    Stand

    Big Fan Pole Stand, Height 280mm, Focusing Range 110mm, Base 290*303*47mm

    Power

    110~240V Wide Range Voltage

    A23.0901-BL3 Zoom Stereo Microscope Optical Data Sheet

    Objective

    Standard 1.0x

    Auxiliary 0.5X

    Auxiliary 1.5X

    Auxiliary 2X

    W,D.

    100mm

    165mm

    45mm

    30mm

    Eyepiece

    Mag

    View field

    Mag

    View field

    Mag

    View field

    Mag

    View field

    10X/20mm

    7.0X

    28.6mm

    3.5X

    57.1mm

    10.5X

    19mm

    14X

    14.3mm

    45.0X

    4.4mm

    22.5X

    8.9mm

    67.5X

    3mm

    90X

    2.2mm

    15X/15mm

    10.5X

    21.1mm

    5.25X

    42.8mm

    15.75X

    14.3mm

    21X

    10.7mm

    67.5X

    3.3mm

    33.75X

    6.7mm

    101.25X

    2.2mm

    135X

    1.7mm

    20X/10mm

    14.0X

    14.3mm

    7.0X

    28.6mm

    21.0X

    9.5mm

    28X

    7.1mm

    90.0X

    2.2mm

    45.0X

    4.4mm

    135.0X

    1.5mm

    180X

    1.1mm


    A23.0901-BL3 Zoom Stereo Microscope Optional Accessories

    Cata. No.

    Head

    Binocular Head + WF10x/20mm

    A23.0901-BH

    Trinocular Head + WF10x/20mm

    A23.0901-TH

    Eyepiece

    WF10x/20mm, High-eyepoint, Outside Dia. 30mm

    A51.0922-10

    WF15x/15mm, High-eyepoint, Outside Dia. 30mm

    A51.0922-15

    WF20x/10mm, High-eyepoint, Outside Dia. 30mm

    A51.0922-20

    WF10x/20mm,with Reticle

    A51.0932-10

    WF15x/15mm,with Reticle

    A51.0932-15

    WF20x/10mm,with Reticle

    A51.0932-20

    Auxiliary Lens

    0.5X,W.D. 165mm

    A52.0927-05

    0.75X,W.D. 105mm

    A52.0927-75

    1.5X,W.D. 45mm

    A52.0927-15

    2.0X,W.D. 30mm

    A52.0927-20

    CCD Adapter

    0.50x, For 1/2" CCD

    A55.0932-05

    0.35x, For 1/3" CCD

    A55.0932-35
