    Motorized Metallurgical Laboratory Microscopes 50X - 1000X A13.1010

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE|Rohs
    Model Number : A13.1010
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Motorized Metallurgical Laboratory Microscopes 50X - 1000X A13.1010


    Motorized Metallurgical Laboratory Microscopes 50X - 1000X A13.1010


    Description:


    A13.1010 Motorized Auto-Focus BF/DF Metallurigcal Microscope, is an ideal instrument for industry inspecition and science research laboratory.

    Intergrate the advantages of modern aesthetics and the edge of disciplines to achieve the automation of microscopes in lab.
    Four motor drive, objective nosepiece, stage and coarse & fine adjustment can be controled manually or motorized.
    Adoption of progressive technological digitl dimmer, which divided the brightness of halogen lamp into 100 step.
    Megapixels camera system, USB 2.0 plugs and play, real time preview is up to 30 fps
    Built-in dynamic focusing system, auto-focus without computer
    Auto-Focusing, High precision positioning leading screw stage, quickly receiveing the clearest images by auto-focus.
    Auto slice scanning, recognizing are controlled by the computer
    Bright/Dark Field Metallurgical microscope
    Full range BF/DF Objectives included
    Polarization system optional
    Powerful transmitted and reflected system with Kohler illumination.

    Network remote control system for real-time teaching etc.


    Specifications:


    A13.1010 Specification
    A
    B
    Optical System
    Infinity optical system
    Head
    Seidentopf trinocular viewing head, inclined at 30°, interpupillarty distance 48mm-75mm
    Eyepiece
    Extra Wide Field Eyepiece EW 10x/22
    Objective
    Infinity Plan Achromatic Objectives 5x/ 0.12/ ∞/ - (BF)
    Infinity Plan Achromatic Objectives 10x/ 0.25/ ∞/ - (BF/DF)
    Infinity Plan Achromatic Objectives 20x/ 0.4/ ∞/ 0 (BF/DF)
    Infinity Plan Achromatic Objectives 50x/ 0.75/ ∞/ 0 (BF)
    Infinity Plan Achromatic Objectives100x/0.9/∞/0 (BF)
    Infinity Plan Achromatic Objectives 40x/0.66/∞/0.17
    Infinity Plan Achromatic Objectives 100x/1.25/∞/0.17
    Stage
    Leading screw stage precision<1μm
    Specimen holder
    Specimen preparation plate
    Slide glass
    Nosepiece
    Quintuple nosepiece
    Camera
    1.3 Mega Pixels CMOS Chip
    Resolution ratio:1280x1024
    Maximum frame rate: 1280x1024 15f/s
    Maximum frame rate: 1024x960 20f/s
    Maximum frame rate: 600x480 30f/s
    Maximum frame rate: 352x288 30f/s
    Maximum frame rate: 320x240 30f/s
    Maximum frame rate: 176x144 30f/s
    Maximum frame rate: 160x120 30f/s
    Responsivity: 1.8v@550um/lux/s
    Exposure: Manuanl or auto exposure,time adjustable (1-500ms)
    SNR:>45dB
    Adapter
    3 BF/DF adapter
    Maximum Sample Height 30mm
    Hardware
    USB2.0 cable
    USB DOG
    The control box of N-800D motorized auto-focus microscope
    9-PIN control port line
    25-PIN control port line
    9-PIN serial port line
    Motorized auto-focus microscope control software
    Adapter
    3.5mm auto focus signal cable
    Focusing
    Auto focus resolution <1μm
    Reflected Illumination
    24V/100W Halogen light, lightness adjustable
    Kohler illumination and aspherical condenser
    Blue,Green,Yellow and Ground glass
    Transmitted
    Illumination
    Swing-out condenser N.A.0.9/ 0.25
    24V/ 100W Halogen light and aspherical condenser
    Blue filter
    Optional Accessories
    Item No.
    Objective
    Infinity Plan Achromatic Objectives 40x/0.6/∞/0 (BF/DF)A5M.1036-40
    Infinity Plan Achromatic Objectives 50x/0.75/ ∞/ 0 (BF/DF)A5M.1036-50
    Infinity Plan Achromatic Objectives 100x/ 0.8/ ∞/ 0 (BF/DF)A5M.1036-100
    Filter
    ND25A5F.1011-25
    ND6A5F.1011-6
    Video AttachmentC Mount 1xA55.1002-10
    C Mount 0.5xA55.1002-05
    Other
    Specimen PresserA50.1010
