Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701

    Buy cheap Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701 from wholesalers

    Buy cheap Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701 from wholesalers
    • Buy cheap Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701 from wholesalers

    Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE, Rohs
    Model Number : A16.0701
    Price : Negotiation
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701

    Inverted Fluorescence Binocular Compound Microscopes 40X - 400X A16.0701



    A16.0701Inverted Fluorescent Microscope

    Optical System

    Infinite Optical System

    Head

    Siedentopf binocular viewing head,inclined at 45°,360° Rotatable, Interpupillary 48-75mm

    Eyepiece

    Ф30 Wide Field Eyepiece WF10×/22,Eyepiece Tube Diameter 30mm

    Objective

    Infinite Plan Achromatic Objective 4x//0.10 WD=22

    Infinite LWD Plan Achromatic Phase Objective 10x/0.25 WD=6

    Infinite LWD Plan Achromatic Phase Objective 20x//0.4 WD=3.1

    Infinite LWD Plan Achromatic Objective 40x/0.55 WD=2.2

    Focusing

    Coaxial coarse and fine adjustment, fine division 2μm,Moving Range up 4.5mm down 4.5mm

    Nosepiece

    Backward Quintuple Nosepiece

    Condenser

    ELWD Condenser NA0.3,LWD72mm(without Condenser 150mm)

    Centering Telescope

    Centering Telescope(φ30mm)

    Phase Annulus

    10x,20x,40x Phase Annulus Plate(Adjustable)

    Stage

    Plain Stage 230×170

    Glasse Insert

    Auxiliary Stage

    Terasaki Holder

    Petri Dish Holderφ38

    Petri Dish Holderφ54

    Attachable Mechanical Stage,X,Y Coaxial Control,Moving Rang 80×120mm

    Illumination

    6V/30W Halogen Lamp, Brightness Adjustable

    Flurenscent Attachment

    Epi-Fluorenscent Illumination

    B,G

    Blue,Green and ground glass ,Diameter 45mm
