    Optical Digital USB Microscope For Laboratory Video Ideo Biological Microscope

    Optical Digital USB Microscope For Laboratory Video Ideo Biological Microscope


    A31.0201 Video Biological Microscope is equipped with achromatic objectives, wide field eyepieces and video trinocular. It provide clear image, wide field, convenience operation. It can observe and display dynamic micro image at the same time. It can be used for biology, medicine, agriculture and industry area widely. It is the ideal instrument in medical treatment, teaching demonstration and scientific research.
    --Built-in CMOS or CCD sensor and video output
    --Coaxial coarse/fine focus system. Minimum division of fine focusing: 2μm
    --6V 20W halogen lamp with brightness control


    A31.0201 Video Biological Microscope

    Video Head

    Built-in clear color 1/3”CMOS sensor, horizontal resolution:380TV lines
    White Balance: Automatic, Color. Video output: 1Vp-p/75ΩNTSC/PAL(optional).
    Power supply adapter:9V DC.

    Eyepiece

    WF10X/18mm

    Objective

    Achromatic 4X/0.10

    Achromatic 10X/0.25

    Achromatic 40X/0.65(Spring)

    Achromatic 100X/1.25(Spring, oil)

    Focus System

    Coaxial coarse/fine focus minimum division of fine focusing: 2μm

    Nosepiece

    Quadruple (Frontward ball bearing inner locating)

    Video Cable

    Standard Video cable, length:1.8m

    Stage

    Double layer mechanical,size:135X125mm, Move range: 75X35mm

    Condenser

    Abbe condenser N.A.=1.25, rack & pinion adjustable

    Filter

    Blue filter

    Frosted filter

    Collector

    For halogen lamp

    Light source

    6V20W halogen lamp, brightness adjustable

    Attachment

    Video cable, length:1.8M


    Optional Accessories

    Item No.

    Eyepiece

    WF16x/11mm

    A51.0203-16A

    Dividing 10x/18mm, 0.1mm/Div

    A51.0205-10

    Objective

    Semi-plan achromatic 4X/0.10

    A52.0202-4

    Semi-plan achromatic 10X/0.25

    A52.0202-10

    Semi-plan achromatic 20X/0.40

    A52.0202-20

    Semi-plan achromatic 40X/0.65(Spring)

    A52.0202-40

    Semi-plan achromatic 100X/1.25(Spring, oil)

    A52.0202-100

    Nosepiece

    Quintuple(Frontward ball bearing inner locating)

    A54.0203-1

    Filter

    Green filter

    A56.0209-2

    Yellow filter

    A56.0209-3
