Infinity Achromatic LED Phase Contrast Microscope 40X - 1000X A19.2701

    Buy cheap Infinity Achromatic LED Phase Contrast Microscope 40X - 1000X A19.2701 from wholesalers

    Buy cheap Infinity Achromatic LED Phase Contrast Microscope 40X - 1000X A19.2701 from wholesalers
    • Buy cheap Infinity Achromatic LED Phase Contrast Microscope 40X - 1000X A19.2701 from wholesalers

    Infinity Achromatic LED Phase Contrast Microscope 40X - 1000X A19.2701

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Certification : CE
    Model Number : A19.2701
    Price : FOB $1~1000, Depend on Order Quantity
    Delivery Time : 5~20 Days
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    • Product Details
    • Company Profile

    Infinity Achromatic LED Phase Contrast Microscope 40X - 1000X A19.2701


    Infinity Achromatic LED Phase Contrast Microscope 40X - 1000X A19.2701


    Specification

    A19.2701 Phase Contrast Microscope

    B

    T

    Optical System

    UCIS Infinity independent achromatic optical system

    Head

    Seidentopf binocular head 30° inclined, 360 ° rotatable interpupillary distance 52-75mm


    Seidentopf trinocular head 30° inclined, 360 ° rotatable interpupillary distance 52-75mm


    Eyepiece

    WF10X/18mm, high eye-point

    Objective

    Infinity Achromatic objective 4x

    Infinity Achromatic phase-contrast objective 10x

    Infinity Achromatic phase-contrast objective 40x(S)

    Infinity Achromatic phase-contrast objective 100(S/Oil)

    Focus System

    Coaxial coarse and fine focus mechanism with markings. Fine focus sensitivity 0.001mm

    Nosepiece

    Quadruple nosepiece inward facing with positive click stops

    Condenser

    N.A. 1.25 Abbe condenser with iris diaphragm, with phase-contrast slide

    Stage

    Mechanical stage with double layers, 142mmx135mm, movement range 76mmx 52mm

    Phase Condenser Attachment

    PH slide 10x, 40x, 100x

    Light source

    6V 20W halogen illumination, brightness adjustable

    3W LED, brightness adjustable
