Opto Edu A41.1940 Binocular Operating Microscope Dual Head Wf12.5x For Orthopedics

    Buy cheap Opto Edu A41.1940 Binocular Operating Microscope Dual Head Wf12.5x For Orthopedics from wholesalers

    Buy cheap Opto Edu A41.1940 Binocular Operating Microscope Dual Head Wf12.5x For Orthopedics from wholesalers
    • Buy cheap Opto Edu A41.1940 Binocular Operating Microscope Dual Head Wf12.5x For Orthopedics from wholesalers

    Opto Edu A41.1940 Binocular Operating Microscope Dual Head Wf12.5x For Orthopedics

    Ask Lasest Price
    Brand Name : OPTO-EDU
    Model Number : A41.1940
    Certification : CE, Rohs
    Price : FOB $1~1000, Depend on Order Quantity
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    Opto Edu A41.1940 Binocular Operating Microscope Dual Head Wf12.5x For Orthopedics

    Operating Microscope, Dual Head, For Orthopedics, Hand, Chest, Burn And Plastic Surgery, Andrology, Genitourinary, Animal Anatomy

    A41.1940 Series Operating Microscopes, is advanced high quality series. It use fibre-optic cable for coaxial illumination, with 3 steps zoom body, has total magnification 2x~30x, featured with Motorized Focusing, it is widely used in hospital for Orthopedics, Hand, Chest, Burn And Plastic Surgery, Andrology, Genitourinary, Animal Anatomy and etc.

    --2 People 2 Binocular Head Same Magnification Same View Field
    --Manual 4 Steps Zoom Body 0.6x,1.0x, 1.0x, 1.6x, Parallel Light System
    --8 Directions Motorized Foot Switch Control Focusing Up/Down, X/Y Moving And Zoom In/Out
    --Four Feet With Locking Wheels, Max Extended Length 1250mm
    --Coaxial Illumination, Light Spot Dia.50mm, Max Brightness 100000 Lux

    A41.1940 Surgical Operation Microscope Specification
    Main UsageOrthopedics, Hand, Chest, Burn And Plastic Surgery, Andrology, Genitourinary, Animal Anatomy
    2 Heads 2 PeopleMain Head Binocular, 45° Inclined, Interpupillary Distance 53~76mm
    Assitant Head Binocular, 45° Inclined, Interpupillary Distance 53~76mm,
    180° Oppsite To Main Head, Same Magnification Same View Field As Main Head
    DiopterBoth Left & Right Eyetube Diopter Adjustable ±6D
    EyepieceWF12.5x
    Zoom BodyMotorized Continues Zoom 1:6, Parallel Light System
    ObjectiveF=200mm
    Total Magnification2x~30x
    View FieldDia.55mm~6mm
    FocusingMotorized Focuing Controled By Foot Switch,
    Focusing Range +/-25mm, Focusing Speed 33s/Full Range, Auto Return To Zero
    Foot Switch8 Directions X/Y/Z + Zoom In/Out Motorized Foot Switch
    --Control Focusing Up/Down, Moving Range 50mm
    --Control X/Y Moving, Moving Range 60mm
    --Control Magnification Zoom In/Out
    --Water Proof Design
    StandLuxury Stand With Control Electrical Parts Built-in
    --Max Extended Length 1250mm
    --Max Rotatable Angle Of Arm 0~300°
    --Distance Between Objective And Gound Surface 800mm~1250mm
    IlluminationCoaxial Illumination, Light Spot Dia.50mm, Max Brightness 100000 Lux
    Weight164Kgs

    Optional AccessoriesCata. No,
    ObjectiveF=175mmA52.1941-175
    F=250mmA52.1941-250
    F=300mmA52.1941-300
    F=350mmA52.1941-350
    Zoom F=180~300mmA52.1941-1830
    AdapterBeamsplitterA55.1941
    C-Mount 0.3x For 1/3" Digital CameraA55.1942
