| Hardware Configuration | A59.4930-2.0M | A59.4930-5.0M | A59.4930-8.0M | A59.4930-12.0M |
| 2.0MP | 5.0MP | 8.0MP | 12.0MP |
| Image Sensor | SONY IM×291 CMOS Sensor | SONY IM×178 CMOS Sensor | SONY IM×274 CMOS Sensor | SONY IM×226 CMOS Sensor |
| Expose Mode | Rolling shutter | Rolling shutter | Rolling shutter | Rolling shutter |
| Maximum Resolution | 1920×1080(2,073600 pixels) | 2592×1944(5,038,848 pixels) | 3840x2160(8,294,400 pixels) | 4000×3000
(12,000,000 pixels) |
| Sensor Optical Format | 1/2.8'' | 1/1.8'' | 1/2.5'' | 1/1.7'' |
| Pixel Size | 2.9μm x 2.9μm | 2.4μm x 2.4μm | 1.62μm x 1.62μm | 1.85μm x 1.85μm |
| Dynamic Range | 128dB | >80dB | >80dB | >80dB |
| SNRmax | 30dB | ≥50dB | ≥50dB | ≥50dB |
| Spectral Characteristics | 380-650nm |
| Exposure Capability | Real-time auto, Single auto, Manual adjustment |
| White Balance | Real-time auto, Single auto, Manual adjust R G B separately |
| Record Format | Snapshot
Picture Format:JPG
Resolution
1920x1080
Record
Video Format:MOV
Resolution
1920X1080@60FPS,
1280x720@60FPS | Snapshot
Picture Format:JPG
Resolution:2592x1944
Record
Video Format:MOV
Resolution:
2592X1944@30FPS,
2560X1920@30FPS,
2048x1536@30FPS,
1920x1080@30FPS | Snapshot
Picture Format:JPG
Resolution
3840x2160
Record
Video Format:MOV
Resolution:
3840X2160@25FPS,
2592X1944@25FPS,
2048x1536@25FPS | Snapshot
Picture Format:JPG
Resolution
4000X3000
Record
Video Format:MOV
Resolution:
4000X3000@15FPS,
4096X2160@25FPS,
3840x2160@25FPS,
2592x1944@25FPS |
| Software Environment (Please confirm mobile display device( tablet
and cell phone)must support protocol IEEE 802.11n/ac, otherwise
they can not display image properly) |
| Windows System Demand | Microsoft®Windows®XP/7/8/8.1/10(32&64 bit) |
| CPU: Dual-core 3.0GHz or more CPU |
| Memory: 4G or more |
| At least 10GB available hard disk space |
| Wireless network card(support IEEE 802.11n/ac) |
| iOS System Demand | iPhone X/8/8Plus/7/7Plus/6s/6s Plus/6/6 Plus/iPad Pro(12.9-inch 2nd
generation)/(12.9-inch 1st generation)/(10.5-inch)/(9.7-inch)/iPad
Air 2/iPad mini 4 |
| Android System Demand | Android 4.0 or higher |
| CPU: dual-core 1.7GHz or higher |
| RAW memory: 1G or more |
| Storage ROM: suggest 8G or larger |
| Operating Environment |
| Operating Temperature | 0℃~ 40℃ |
| Storage Temperature | -20℃~ 60℃ |
| Operating Humidity | 30~60%RH |
| Wireless Parameter/Power Parameter |
| Standard | IEEE 802.11n/ac |
| Operating Frequency Range | 2412---2484MHz &5180---5825MHz |
| Data Transmission Rate | IEEE 802.11n: MCS0-MCS7@ HT 20/2.4GHz band |
| IEEE 802.11n: MCS0-MCS9@ HT 40/5GHz band |
| IEEE 802.11n: MCS0-MCS7@ VHT 80/5GHz band |
| Receiving Sensitivity | HT20 MCS7: -71dBm@10% PER(MCS7)/2.4GHz band |
| VHT80 MCS9:-60dBm@10% PER(MCS9)/5GHz band |
| HT40 MCS7:-70dBm@10% PER(MCS9)/2.4GHz band |
| Transmission Powder | IEEE802.11ac:13±1.5dBm@HT80 MCS9/5GHz band |
| IEEE802.11n:16±1.5dBm@HT20/40 MCS0/5GHz band |
| IEEE802.11n:16±1.5dBm@HT20/40 MCS7/2.4GHz band |
| The Wireless Work Instructions | When there has not WiFi, LED lamp turn off |
| When WiFi is opened but do not connect, LED is always lighting |
| When WiFi is connected, LED flashes at the beginning and stay turn
off afterward |
| When WiFi is connected, LED flashes, about once per second, the
greater the amountof data the faster it flashes, and it is about 10
times per second |
