Finite Optical System Biological Microscope With Coaxial Coarse and Fine Focusing A12.1035

Specification

A12.1035 Biological Microscope		B	T	BE	TE
Optical System	Finite Optical System
Eyepiece	WF10X/18
Viewing Head	Monocular Head Inclined at 30°	○	○	○	○
	Seidentopf Binocular Viewing Head Inclined at 30°, Interpupillary 47-78mm	●		●
	Seidentopf Trinocular Viewing Head Inclined at 30°, Interpupillary 47-78mm		●		●
	Digital Viewing Head Inclined at 30°, Interpupillary 47-78mm, 5M pixels, Support Wifi	○	○	○	○
	Digital Viewing Head Inclined at 30°, Interpupillary 47-78mm, 5M pixels, 8" LCD. Android OS	○	○	○	○
Achromatic Objective	4X N.A=0.1 WD=37.5	●	●	●	●
	10X N.A=0.25 WD=7.316	●	●	●	●
	20X N.A=0.4 WD=13	○	○	○	○
	40X N.A=0.65 WD=0.632	●	●	●	●
	100X N.A=1.25 WD=0.198	●	●	●	●
Nosepiece	Backward Quadruple Nosepiece	●	●	●	●
Stage	Double Layers Mechanical Stage 140X140mm, Moving Range 75X50mm
Condenser	NA1.25 Abbe Condenser	●	●	●	●
Condenser	Dark Field Condenser (Dry, Oil)	○	○	○	○
Focusing System	Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Range 25mm
Illumination	Halogen Lamp 6V/20W	○	○	○	○
	S-LED Illumination	●	●	●	●
	S-LED Illumination with Recharger	○	○	○	○
	Kohler Illumination	○	○	○	○
	ECO Function (Auto Power Off After 30 Mins No Operation)	○	○	●	●
	Plane-concave Mirror	○	○	○	○
Fluorescent Attachment	Fluorescent Illumination, LED Lamp	○	○	○	○
Fluorescent Attachment	Fluorescent Illumination, 100W HBOLamp	○	○	○	○
Polarzation Set		○	○	○	○
Phase Contrast Kit		○	○	○	○

Note: ● Standar Outfit , ○ Optional
