Brand Name : | CNOEC, OPTO-EDU |
Model Number : | A13.2700 |
Certification : | CE|Rohs |
Price : | FOB $1~1000, Depend on Order Quantity |
Payment Terms : | T/T, West Union, Paypal |
Supply Ability : | 5000 pcs/ Month |
Delivery Time : | 5~20 Days |
Infinity Binocular Trinocular Metallurgical Optical Microscope A13.2700
Description:
A13.2700 Metallurgical Microscope, with flexible system, excellent imaging
performance and stable system achritecure. It is professional used
in industrial testing and metallographic analysis. The operating
mechanism according to ergonomic design. That can maximum reduce
fatigue during using. Modular component design can freely assemble.
--Variety of Observation Methods To Have Sharp and High Contrast
Microscopic Image
--Accessories Complete, Well Equipped, The System Can be Flexibly
Combined
--Ergonomic Design, Reliable System Architecture
Specification | ---------------A13.2700-A
----------------------------------------A13.2700-B------------------ | ||
---|---|---|---|
Head | Binocular Head,30° Inclined, 360° Rotatable, Interpupillary Distance 52-75mm, ±5 Diopter Adjustment | Trinocular Head,30° Inclined, 360° Rotatable, Interpupillary Distance 52-75mm, ±5 Diopter Adjustment | |
Eyepiece | Plan WF10x/18mm, High Eyepoint Up To 21mm | ||
Objective | Infinity LWD Plan Achromatic Objective 10x, 20x(S), 50x/(S),80x (S) | ||
Focus System | Low Positioned, Coaxial Coarse & Fine Focusing System With An Adjustable Tension Control And Upper Limit Stop, Coarse 14mm/Rot, Fine 0.1mm/Rot, Minimum Reading 1mm On Left-Side Fine Knob, Moving Range 20mm | ||
Nosepiece | Quadruple,Reversed Type With Positive Click Stops | ||
Stage | Mmechanical Stage (For Refected Illumination), Size 142x135mm, Moving Range 76x52mm. Low Position, Right Hand Control, X-Y Coaxial Control Knob | ||
Polarization | With Polarizer (Reflected) & Analizer | ||
Illumination | Reflected, Halogen 12V50W, With Polarizer & Analizer | ||
Power Supply | 100-240V Wide Power Range, CE certified | ||
Adapter | 1x C-Mount | ||
A12.2700 Metallurgical Microscope Optional Accessories | Item No. | ||
Head | Binocular Head,30° Inclined, 360° Rotatable, Interpupillary Distance 48-75mm, ±5 Diopter Adjustment | A53.2702-3A | |
Trinocular Head,30° Inclined, 360° Rotatable, Interpupillary Distance 48-75mm, ±5 Diopter Adjustment | A53.2704-3A | ||
Eyepiece | WF10x/20mm, Plan, High Eyepoint Up To 21mm | A51.2701-10B | |
WF16x/13mm,Plan | A51.2701-1613 | ||
WF10x/18mm, Plan, With Pointer | A51.2702-10 | ||
WF10x/18mm Plan, Reticule Eyepiece | A51.2703-10 | ||
Objective | Infinity LWD Plan Achromatic 5x | A5M.2731-05 | |
Nosepiece | Upgrade To Quintuple,Reversed Type With Positive Click Stops | A54.2705-A1 | |
Adapter | 1.0x C-Mount | A55.2701-10 | |
0.5x C-Mount | A55.2701-05 | ||
0.25x C-Mount | A55.2701-25 | ||
For Digital Eyepiece (To Be Used On Trinocular Tube) | A55.2701-8 | ||
Digital Camera Adapter, (Need To Know Camera Model) | A55.2702-2 |
![]() |
