    A63.7006 Sem Scanning Electron Microscope 20x~60000x

    Ask Lasest Price
    Brand Name : OPTO-EDU
    Model Number : A63.7006
    Certification : CE, Rohs
    Price : FOB $1~100000, Depend on Order Quantity
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    A63.7006 Sem Scanning Electron Microscope 20x~60000x

    Tungsten Filament Scanning Electron Microscope, SE, 20x~60000x

    • 20x~60000x Resolution 15nm With Detector SE, Optional BSE, EDS, CCD
    • Standard X/Y/R 3 Axes Working Stage, Optional Five Axes Working Stage X/Y/Z/R/T
    • 2-Stage Electromagnetic Condenser Lens, 1-Stage Electromagnetic Objective Lens
    • Vaccum System: 1 Turbo Molecular Pump+ 1 Mechanical Rotary Pump
    • Auto Start, Auto Focus, Auto Brightness, Contrast Adjust












    Tungsten Filament Scanning Electron Microscope (SEM)
     A63.7006A63.7015
    Resolution15nm@30KV(SE)5nm@30KV(BSE)
    Magnification20x~60000x20x~150000x
    Electron GunPre-Centered Tungsten Filament Cartridge, Bias Voltage Auto System
    VoltageAccelerating Voltage 1KV to 30KV,
    1KV/5KV/10KV/15KV/20KV/30KV-6 Steps
    Lens System2-Stage Electromagnetic Condenser Lens,
    1-Stage Electromagnetic Objective Lens
    Aperture-Adjustable Iris Diaphragm 30/50/50/100um, Change Electro Beam To Get High Resolution Image
    Vacuum SystemRotary Pump, 100Liters/min
    Turbo Molecular Pump, 70Liters/sec
    Pump Down Ttime <3 Minutes
    Fully Auto Vacuum Control
    DetectorSE: Secondary Electron Detector
    BSE: Back Scattering Detector (Optional)
    EDS: (Optional)
    Specimen Working Stage3 axis System,X, Y-axis : 35mm / R-axis : 360°5-axis System , X, Y-axis : 35mm / R-axis : 360°, Z : 0~22mm / Tilt-axis : 0~45°
    Max Specimen70mm in Diameter, 30mm in Height80mm in Diameter, 35mm in Height
    Image ShiftX, Y Image Shift ±150um
    Image Scanning SystemFast Scan: 320x240 (Scan Time: 0.1 sec.)
    Slow Scan: 640x480 (Scan Time: 3 sec.)
    Photo Mode 1: 1280x960
    Photo Mode 2: 2560x1920
    Photo Mode 3: 5120x3840
    Image FormatBMP, JPEG, PNG, TIFF
    Auto FunctionAuto Start, Auto Focus, Auto Brightness/Contrast
    Photo DisplayMagnification, Detector type, Accelerating Voltage, Vacuum mode, Logo(Text), Date & Time, Text Marker, Scale Bar, etc.
    Computer & SoftwarePC Work Station Win 10 System, With Professional Image Analysis Software To Fully Control Whole SEM Microscope Operation, Computer Specification No Less Than Inter I5 3.2GHz, 4G Memory, 24" IPS LCD Monitor, 500G Hard Disk, Mouse, Keyboard
    Size & WeightMicroscope Body 460x600x950mm, Total Weight 95Kg
    A63.7006, A63.7015 Standard Tools & Parts Outfit
    1Pre Centered Tungsten Filament5 pcs/box
    2Sample Stage Dia. 15mm10 pcs
    3Sample Stage Dia. 25mm10 pcs
    4Sample Stage Dia. 15mm 45° Tilt5pcs
    5Sample Stage Dia. 15mm 90° Tilt5pcs
    6Height Standard Master1 pc
    7Allen Wrench1 set
    8SEM Software CD1 pc
    9Carbon Conductive Tape)1 pc
    10Scissors1 pc
    11Aurilave1 pc
    12Tweezers1 pc
