    A43.1901 C Mount 1/3" Ccd Surgical Operating Microscope 2.9x - 21.7x Colposcope

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Model Number : A43.1901
    Certification : CE,
    Price : FOB $1~1000, Depend on Order Quantity
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    A43.1901 C Mount 1/3" Ccd Surgical Operating Microscope 2.9x - 21.7x Colposcope

    Specifications
    ModelA43.1901-AA43.1901-BA43.1901-CA43.1901-DA43.1901-E
    Observation angle45° Tilted Binocular Observation Unit
    Magnification of eyepiece16X
    Focal length of objectiveF=230mm & 280mm (Connecting screw: M58x0.75)F=280mm
    (Connecting screw: M57x0.75)
    Working distance215mm & 260mm265mm
    Magnification changer0.4X, 0.66X, 1X, 1.5X, 2.5X
    5-step magnification change
    No
    Total magnification2.9X-21.7X11X
    Linear field11mm - 84mm24mm
    Beamsplitter50:50 BeamsplitterNo
    DemonstratorTotal magnification:2.1X-16.4XOptional
    TV adapterC-mount 1/3" CCD attachableNo
    Photo adapterOptionalNo
    Fine focusing distance20mm60mm20mm
    Balancing armCounterweight adjustableNoCounterweight adjustable
    Illumination systemCoaxial illumination with cold light source fiber-optic cable
    12V 100W halogen lamp, brightness adjustable
    FilterGreen filter with frame, to be fitted on the objective when it is used
    Fiber-optic cable1300mm
    Standshort column fitted on the round base with 5 jaws and a round counterweight ringColumn height adjustable fitted on the round base with 3 jawsshort column fitted on the round base with 5 jaws
