    Halogen Lamp Dental Microscopes Binocular Stereo Optical Lab Equipment A41.3406

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Model Number : A41.3406
    Certification : CE,
    Price : FOB $1~1000, Depend on Order Quantity
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    Halogen Lamp Dental Microscopes Binocular Stereo Optical Lab Equipment A41.3406

    A41.3406 Operating binocular microscope dental lab equipment

    Product Description

    A41.3406 OPERATION MICROSCOPE(MULTI-SECTION) dental lab equipment
    ---Five-step magnifications for main microscope, three-step magnifications for assistant microscope; Fine focusing for assistant microscope keeps the same clearness as main microscope.
    ---Lens made of imported glass from Germany can reduce the optical aberration.
    ---All of the lens are multi-coated, mildewproof and anti-reflection
    ---Equipped with two Objectives and being applicable to ophthalmology, neurosurgery, orthopaedics, microscope surgery.
    --- Inclination directions and angles are controlled by hand and motor.
    ---Magnification and five-step fine focusing are controlled by hand and motor.
    ---Independent electrical box has the function of automatical diagnosis, which is very convenient for repair if necessary.

    Eyepiece Magnification12.5×/18B
    Adjustable Dioptor±5D
    Adjustable range for Pupil Distance50mm~75mm
    Illumination Source15V/150W,Halogen Lamp
    Illumination TypeCoaxial Illumination, illumination and light spot adjustable
    Coaxial Illumination≥30000lx
    Reaching Range of Arm1230mm
    Adjustable Vertical Range850mm~1350mm
    Fine Focusing speed and range1mm/s~3mm/s,≤50mm
    Horizontal Inclination Range±60°
    Adjustable Pitching Range(compared with vertical axis)vertical axis) Adjusting range Depends on locking angle of the arm carrying microscope:When locked at 0°, the adjustable range -5°~+100°When locked at 30°, the adjustable range -5°~+90°When locked at 60°, the adjustable range -5°~+70°
    VoltageAC220V±10%/50Hz±1Hz,AC110V±10%/60Hz±1Hz
    Power200VA
    FuseAC250V T3.15A,AC125V T6.3A
    Electrical Safety StandardConform to Standard IEC 601-1.Class1Type B
    Whole Packing Volume0.731m3
    Carton Number5
    Total Weight215kg
    Optional Accessory
    -- Teaching tube, Beam Splitter.
    ---1/3” CCD camera, CCD Adaptor, Beam Splitter and relevant Cables.
    ---f400mm Objective
    Company Information


    OPTO-EDU, as one of the most professional manufacturer and supplier of microscope in China, our sub-brand CNOPTEC series high end biological, laboratory, polarizing, metallurgical, fluorescene microscopes, CNCOMPARISON series forensic microscope, A63 series SEM microscope, and .49 series digital camera, LCD camera are very popular in the world market.
