LED OPTO-EDU A18.4902 Digital Comparison Microscope 3840 X 2160
Maximum Resolution
| A18.4902 Digital Forensic Comparison Microscope Specification |
| Hardware configuration |
| Image Sensor | SONY IMX274 COMS Sensor |
| Expose Mode | Rolling Shutter . |
| Maximum Resolution | 3840 x 2160 (8,294,400 pixels) |
| Sensor Optical Format | 1/2.5'' |
| Pixel Size | 1.62μm x 1.62μm |
| Dynamic Range | >80dB |
| SNRmax | ≥50dB |
| Spectral Charactristics | 380-650nm |
| Exposure Capability | Real-time Auto, Single Auto, Manual Adjustment |
| White Balance | Real-time Auto, Single Auto, Manual Adjust R G B Seperately |
| Record Format | Snapshot
Picture Format: JPG
Resolution: 3840x2160
Record
Video Format: MOV
Resolution: 3840X2160@25FPS,2592X1944@25FPS,2048x1536@25FPS |
| Optical Parameters |
| Optical Magnification Of Lines | 0.83x~10x |
| Optical Resolution Of Lines(um) | 5um |
| Working Distance(mm) | 72mm |
| Observation Range(mm) | 0.65x0.36~8.2x4.6mm |
| Comprehensive Magnification | Full Screen Display On A 21-inch 16:9 Minitor:57x~715x |
| Full Screen Display On A 17-inch 16:9 Minitor:46x~578x |
| Working Stage | Square Manual Working Stage 120*120*43mm, Moving Range 55*55*55mm |
| Joint Left/Right Moving Range 80mm, Joint Up/Down Range 150mm |
| Clamp Working Stage Dia.100mm, 360° Rotatable |
| Round Titable Working Stage Moving Range 0-14.5mm, 45°-90°
Inclined, 360° Rotatable |
| Ring LEDs( Coaxial & Diffuse LED ) Parameters |
| Power | <3W |
| Input Voltage | DC 5V |
| Dimming Method | 0-100% Linear Adjustment |
| Centric Brightness | Coaxial: ≥12000LX (Height 100mm) |
| Diffuse Reflection: ≥42000LX (Height 100mm) |
| Number Of LEDs | Coaxial Light: 13 Small Angle Highlighting Lamp Beads |
| Diffuse Light: 40 Bright White LEDs |
| Color Temperature | 5000K~5500K |
| Adjustment Method | Separate Control (Independently Controlled By One Knob For One Kind
Of Light) |
| Seven-color LED Parameters |
| Power | <3W |
| Input Voltage | DC 5V |
| Dimming Method | 0-100% Linear Adjustment |
| Comprehensive Magnification | Red: 610um |
| Yellow: 600um |
| Warm White: 586um |
| Green: 528um |
| White: 494um |
| Purple: 458um |
| Blue: 470um |
| Adjustment Method | Brightness And Light Switching Are Controlled By Different Knobs |
| Software Environment |
| Windows System Demand | Microsoft ® Windows ® XP / 7 / 8 /8.1/10(32 & 64 bit) |
| CPU: Dual-core 3.0 GHz Or More CPU |
| Memory: 4G Or More |
| Network:10/100/1000Mbps Compatitable Interface |
| At Least 10 GB Available Hard Disk Space |
| Operating Environment |
| Operating Temperature | 0℃~ 40℃ |
| Storage Temperature | -20℃~ 60℃ |
| Operating Humidity | 30~60%RH |
| Storage Humidity | 10~80%RH |
