    Objective 10x Binocular Metallurgical Optical Microscope Halogen 100 - 240V

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Model Number : A13.2605-A
    Certification : CE, Rohs
    Price : FOB $1~1000, Depend on Order Quantity
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    Objective 10x Binocular Metallurgical Optical Microscope Halogen 100 - 240V

    OPTO-EDU A13.2605-A 50X-500X Binocular Metallurgical Microscope


    A13.2605 metallurgical microscope is designed for material surface observation and mechanical state detection. It can accurately display the color of different metals and easy to use for analysing the internal structure of electronic products. One of the main part of the microscope is metallurgical epi illumination, the light source is reflect 6V30W Halogen Lamp.

    Objective 10x Binocular Metallurgical Optical Microscope Halogen 100 - 240V
    Objective 10x Binocular Metallurgical Optical Microscope Halogen 100 - 240V

    Objective 10x Binocular Metallurgical Optical Microscope Halogen 100 - 240V

    Seidentopf Head
    Inclined 30°,Rotatable 360°, Interpupillary Distance 48-75mm, High Eyepoint Eyepiece, Which Is Convenient For

    People With Different Sitting Height; The Integrated Design Of The Eyepiece Lens Barrel, Avoids The Loss And

    Contamination Of The Eyepiece And Enhances The Integrated Performance Of The Microscope
    Objective 10x Binocular Metallurgical Optical Microscope Halogen 100 - 240V

    Nosepiece & Objective
    High Precision Reserved Quadruple, Backward Nosepiece, Metallurgical LWD Infinity Plan Objectives: 5x, 10x, 50x; Optional 20x, 80x, 100x
    Working Stage
    Double Layer Mechanical Stage Size 200×140mm, Travel Range 76×52mm
    Objective 10x Binocular Metallurgical Optical Microscope Halogen 100 - 240V
    Objective 10x Binocular Metallurgical Optical Microscope Halogen 100 - 240V

    Powered By Safety Low Voltage Charger
    Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use

    ItemsA13.2605 Metallurgical Microscope SpecificationABCata. No.
    HeadSeidentopf Binocular Head Inclined 30°, Eyetube Rotatable 360°, Interpupilary Distance 48-75mm A53.2621-B
    Seidentopf Trinocular Head Inclined 30°, Eyetube Rotatable 360°, Interpupilary Distance 48-75mm, Light Split Fixed P20/E80 A53.2621-T
    EyepieceWF10x/20mm, High Eyepoint,A51.2602-1018
    WF10x/20mm, With Micrometer X-0.1mm*180 Div / Y-Single Line, Diopter AdjustableA51.2605-1018D
    NosepieceQuadruple, Backward●●●●A54.2610-N734
    Metallurgical LWD Infinity Plan ObjectivesLPL 5x/0.13, W.D.=16.04mmA5M.2633-5
    LPL10x/0.25, W.D.=18.48mmA5M.263310
    LPL 20x/0.40, W.D.=8.35mmA5M.2633-20
    LPL 50x/0.70, W.D.=1.95mmA5M.2633-50
    LPL 80x/0.80, W.D.=0.85mmA5M.2633-80
    LPL 100x/0.90(Dry), W.D.=1.00mmA5M.2633-100
    Working StageDouble Layer Mechanical Stage Size 200×140mm, Travel Range 76×52mmA54.2601-S04T
    FocusingCoaxial Coarse And Fine Focusing Knobs,
    Travel Range: 22mm, Scale: 2µm

    IlluminationReflect Light Source, 5WLED Warm Lamp, With Five Holes Filter Disc (Blue, Green, Amber, Grey, Empty)
    Powered By Safety Low Voltage Charger, Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use
    A56.2613-6V30W
    PolarizingAnalyzer + PolarizerA5P.2603-BS
    AdapterC-Mount 0.5x, Focus AdjustableA55.2601-05
    C-Mount 0.75x, Focus AdjustableA55.2601-75
    C-Mount1.0x, Focus AdjustableA55.2601-10
    Digital Eyepiece Camera Adapter, Dia. 23.2mm/25mmA55.2610
    PackageCarton Size 570*275*450mm, 1 Unit/Ctn
    WeightGross Weight 10.5kgs, Net Weigth 8.0kgs
    Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.
