    40 - 400x Student Compound Microscope Digital Biological Microscope

    OPTO-EDU A15.2603-B 400X Trinocular Illumination Polarizing Microscope
    A15.2603 Polarizing Microscope, with full polarizing function and high quality performance, is the best tools for school and student use.
    --Infinity achromatic correction optical system, infinity without stress flat field objective.
    --Polarizer unit built-in condenser, with scale, rotatable 360°, can be locked.
    --Analyzer unit insert to polarizing media, rotatable 0-90°, can be moved out of optical path.
    --Optical compensator: λ slip (first class red), 1/4λ slip.


    Parameter:

    A15.2603-A-B
    HeadBinocularTrinocular
    Seidentopf Head, Inclined 30°, Rotatable 360°, Interpupillary Distance 48-75mm, Left Eyepiece Tube Diopter Adjustable +/-5°, Trinocular Head Light Split 20:80.
    EyepieceWF10x/18mm, 1 pc
    WF10x/18mm, With Micrometer 0.1mm Div., 1 pc
    NosepieceQuadruple, Center Adjustable
    ObjectiveNon-Stress Infinity Plan Objective
    4x/0.10
    10x/0.25
    20x/0.40(S)
    40x/0.65(S)
    StageRound stage, Rotatable 360°, Center Adjustable, Division 1°, Vernier Division 6'
    CondenserAbbe N.A.1.25, With Iris Diaphragm, Non Stress
    FocusingCoaxial Coarse and Fine Focusing Knob, Coarse Focusing Range 26mm, Fine Focusing Scale 2μm, With Tension Adjustment
    PolarizingPolarizer: Unit Built-in Condenser, With Scale, Rotatable 360°, Can Be Locked
    Analyzer: Unit Insert to Polarizing Media, Rotatable 0-90°, Can Be Moved Out Of Optical Path
    Polarizing Media, Between Head & Body, Including Compensator
    --Bertrand Lens, Built-in, Center Adjustable, Can Be Moved Out Of Optical Path
    --λ Slip (First Class Red)
    --λ/4 Slip
    --Quartz Wedge I~IV Class Slip
    IlluminationTransmit 6V20W Halogen Lamp
    Power110V~240V Wide Range Voltage
    Product Display

    Seidentopf Trinocular Head Inclined 30°,Rotatable 360°, Interpupilary Distance 48-75mm, Light Split Fixed P20:E80
    Eyepiece WF10x/18mm, With Micrometer X-0.1mm*180 Div / Y-Single Line, Diopter Adjustable


    Analyzer Media Unit, Between Head And Body, Analyzer 0~90° Adjustable,
    With Betrand Lens Built-in, Can Be Moved Out Of Optical Path For Single Polarizing Observe
