Bright Field Halogen Lamp Microscope Digital Metallurgical Microscope A13.0210

    Buy cheap Bright Field Halogen Lamp Microscope Digital Metallurgical Microscope A13.0210 from wholesalers

    Buy cheap Bright Field Halogen Lamp Microscope Digital Metallurgical Microscope A13.0210 from wholesalers
    • Buy cheap Bright Field Halogen Lamp Microscope Digital Metallurgical Microscope A13.0210 from wholesalers

    Bright Field Halogen Lamp Microscope Digital Metallurgical Microscope A13.0210

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Model Number : A13.0210
    Certification : CE|Rohs
    Price : Negotiation
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    Bright Field Halogen Lamp Microscope Digital Metallurgical Microscope A13.0210


    APO Metallurgical Microscopes Bright Field Microscopes Rohs CE A13.0210



    Specifications:

    Specification
    A13.0210 Metallurigical Microscope
    A
    B
    Eyepiece
    Wide field WF10X(field number:Φ22mm)
    Infinity Plan Achromatic ObjectivePL L10X/0.25 (Work distance):20.2 mm(Equipped with bright field objectives)
    PL L20X/0.40 (Work distance):8.80 mm(Equipped with bright field objectives)
    PL L50X/0.70 (Work distance):3.68 mm(Equipped with bright field objectives)
    PL L100X/0.85 (Dry)Work distance):0.4 mm(Equipped with bright field objectives)
    PL L5X/0.12 BD (Work distance):9.7 mm(Equipped with bright & dark field objectives)
    PL L10X/0.25 BD (Work distance):9.30 mm(Equipped with bright & dark field objectives)
    PL L20X/0.40 BD (Work distance):7.23mm(Equipped with bright & dark field objectives)
    PL L50X/0.70 BD (Work distance):2.50 mm(Equipped with bright & dark field objectives)
    Eyepieces Tube
    Inclination angle is 45°and interpupillary distance is 53~75mm.
    Focus System
    Coaxial coarse/fine focus system, with tension adjustable and limit stopper, minimum division of fine focusing: 2μm
    NosepieceQuintuple (Backward ball bearing inner locating)
    Stage
    Mechanical stage,overall size:242mmX200mm,moving range: 30mmX30mm
    Rotundity and rotatable stage size: maximal measurement is Ф130mm and minimal clear aperture is less then Ф12mm.
    Illumination System
    6V30W halogen and brightness enable control.
    12V50W halogen and brightness enable control.
    Integrated field diaphragm , aperture diaphragm and puller type polarizer.
    Equipped with frosted glass and yellow ,green and blue filters
    Optional Accessories
    Item NO.
    EyepieceDividing eyepiece(field number:Φ22mm) 0.10mm/Div
    A51.0205-G10B
    ObjectivePL L5X/0.10 (Work distance):26.12 mmEquipped with bright field objectives
    A5M.0235-5
    PL L40X/0.60 (Work distance):3.68 mm
    A5M.0235-40
    PL L60X/0.70 (Work distance):3.18 mm
    A5M.0235-60
    PL L80X/0.80 (Work distance):1.28 mm
    A5M.0235-80
    PL L40X/0.60 BD (Work distance):3.00 mmEquipped with bright & dark field bjectives
    A5M.0237-40
    PL L60X/0.70 BD (Work distance):1.90 mm
    A5M.0237-60
    PL L80X/0.80 BD (Work distance):0.80mm
    A5M.0237-80
    PL L100X/0.85 BD (Work distance):0.22 mm
    A5M.0237-100
    CCD Adapter0.5X
    A55.0202-4
    1X
    A55.0202-2
    0.5X with dividing 0.1mm/Div
    A55.0202-3
    Digital Camera AdapterCANON EF digital SLR camera adapter
    A55.0204-01
