40x - 400x Binocular Metallurgical Optical Microscope Halogen Lamp A13.1017 OPTO-EDU

    Buy cheap 40x - 400x Binocular Metallurgical Optical Microscope Halogen Lamp A13.1017 OPTO-EDU from wholesalers

    Buy cheap 40x - 400x Binocular Metallurgical Optical Microscope Halogen Lamp A13.1017 OPTO-EDU from wholesalers
    • Buy cheap 40x - 400x Binocular Metallurgical Optical Microscope Halogen Lamp A13.1017 OPTO-EDU from wholesalers

    40x - 400x Binocular Metallurgical Optical Microscope Halogen Lamp A13.1017 OPTO-EDU

    Ask Lasest Price
    Brand Name : CNOEC, OPTO-EDU
    Model Number : A13.1017
    Certification : CE|Rohs
    Price : Depend on Order Quantity
    Payment Terms : T/T, West Union, Paypal
    Supply Ability : 5000 pcs/ Month
    Delivery Time : 5~20 Days
    • Product Details
    • Company Profile

    40x - 400x Binocular Metallurgical Optical Microscope Halogen Lamp A13.1017 OPTO-EDU


    Forensic Laboratory Metallurgical Optical Microscope 40x - 400x A13.1017


    Specifications:


    Specification A13.1017
    A
    B
    Head
    Binocular Head
    -
    Trinocular Head
    -
    Eyepiece
    WF10×/18
    Objective
    Infinity Plan Achromatic Objectives 4×/0.1/∞/- WD25.4mm
    Infinity Plan Achromatic Objectives 10x/ 0.25/ ∞/ - (BF/DF)
    Infinity Plan Achromatic Objectives 10×/0.25/∞/- WD11.0mm
    Infinity Plan Achromatic Objectives 40x/0.60/∞/- WD2.9mm
    Stage
    Double layer mechanical stage150×140mm/75×50mm
    Nosepiece
    Quadruple Nosepiece
    Adapter
    3 BF/DF adapter
    Maximum Sample Height
    30mm
    Focusing
    Coaxial Fine & Coarse Adjustment
    Illumination
    Kohler Illumination, Epi-illuminator with iris aperture diaphragm and iris field diaphragm, 6V/20W Halogen Lamp, Brightness Adjustable
    Filters
    Blue
    Green
    Yellow
    Ground Glass
    Optional Accessories
    Item No.
    Eyepiece
    WF8x/18A51.1002-8
    WF10x/18 with 0.1mm Micrometer & Cross HairA51.1007-10M
    WF12.5x/15A51.1004-12.5
    Objective
    Infinity Plan Achromatic Objectives5x/0.12/∞/- WD45.5mmA5M.1035-5
    Infinity Plan Achromatic Objectives 20x/0.40/∞/- WD5.8mmA5M.1035--20
    Infinity Plan Achromatic Objectives 40x/0.65/∞/- WD0.52mmA5M.1035--40
    Infinity Plan Achromatic Objectives 50x/0.75/∞/- WD0.32mmA5M.1035--50
    Infinity Plan Achromatic Objectives 80x/0.90/∞/- WD0.2mmA5M.1035--80
    Infinity Plan Achromatic Objectives 100x/0.90/∞/0 WD0.7mmA5M.1035--100
    Illumination
    Diascopic Illumination, 6V/20W Halogen Lamp, Brightness AdjustableA56.1003-1
    Specimen Presser
    A5M.1010
    Polarizing Attachment
    A5P.1004
