Brand Name : | CNOEC, OPTO-EDU |
Model Number : | A18.1826 |
Certification : | CE, Rohs |
Price : | Depend on Order Quantity |
Payment Terms : | T/T, West Union, Paypal |
Supply Ability : | 5000 pcs/ Month |
Delivery Time : | 5~20 Days |
OPTO-EDU A18.1826 3.36~216x Binocular 45° Inclinded Forensic bullet Comparison Microscope
A18.1826 Comparsion Microscope | |
Total Magnification | 3.36x-216x |
Head | Binocular 45° Inclinded, 48-75mm |
Eyepiece | WF10X/22mm, WF20X/12mm |
Zoom Lens | 0.7-4.5x |
Bridge Magnification | 1.2x |
Auxiliary Lens | 0.4x, 2.0x |
View Field | Full Left, Full Right, Split Image, Overlapping Image, 2mm-60mm |
Working Stage | Moving Range: X-54mm, Y-54mm, Z-54mm, 0°-45° Inclination Adjustable |
Joint Left/Right Moving Range 62mm, Joint Up/Down Range 62mm | |
Round Stage, 360° Rotating | |
Bullet Holder 2 Sets | |
Light Source | 5W LED+12V/50W Halogen Coaxial Light Polarizing Light UV Filter Filter Red/Blue/Yellow/Green |
Adapter | 0.5x C-Mount |
Photo Adapter For Cannon SLR | |
Function Panel | Touch Type, User-Friendly Design, Easy To Operate And Accurate |
Power | Power Supply 80-240V |
![]() |
