| Research Laboratory Ultra LED Fluorescent Microscope | A16.2610 | Cata. No. |
| Eyepiece | WF10x/25mm, High Eyepoint, Diopter Adjustable | ●● | A51.2621-1025 |
| WF10x/23mm, High Eyepoint, Diopter Adjustable | ○○ | A51.2621-1023 |
Infinity Plan Objective
(F.N.25) | PLAN 4X /0.11, W.D.12.1mm | ○ | A52.2610-4 |
| PLAN 10X /0.25, W.D.10.0mm | ○ | A52.2610-10 |
| PLAN 20X /0.45, W.D.3.33mm | ○ | A52.2610-20 |
| PLAN 40X /0.70 (S), W.D.2.61mm | ○ | A52.2610-40 |
| PLAN 100X /1.25 (S,Oil), W.D.0.25mm | ○ | A52.2610-100 |
| PLAN 2X /0.06, W.D.7.2mm | ○ | A52.2606-2 |
Infinity Plan
Semi-APO
Objective
(F.N.25) | PLAN S-APO 4X /0.10, W.D.16.2mm | ● | A52.2611-4 |
| PLAN S-APO 10X /0.30, W.D.9.6mm | ● | A52.2611-10 |
| PLAN S-APO 20X /0.45, W.D.2.8mm | ● | A52.2611-20 |
| PLAN S-APO 40X /0.70 (S), W.D.0.55mm | ● | A52.261140 |
| PLAN S-APO 100X /1.25 (S,Oil), W.D.0.21mm | ● | A52.2611-100 |
| Head | Trinocular Head, Inclined 30°, Rotatable 360°, Interpupillary
Distance 48-76mm, 3 Light Split Ratio: E100:P0, E80:P20, E0:P100 | ● | A53.2610-T18 |
| Trinocular Head, Inclined 30°, Rotatable 360°, Interpupillary
Distance 48-76mm, 2 Light Split Ratio: E100:P0, E80:P20 | ○ | A53.2610-T13 |
| Nosepiece | 6 Holes Nosepiece, Inward | ● | A54.2610-N6 |
| Working Stage | Double Layer Rackless Mechanical Stage, Size 280x160mm, Moving
80x52mm, Double Slide Holder | ● | A54.2601-AT280 |
| Condenser | Swing-out Condenser N.A.0.9/0.13, With Scale, Can Be Locked, | ● | A56.2614-C11 |
| Polarizing | Analyzer, Put In Slide Insert To Hole On Nosepiece
Polarizer, Put On Stand Light Collector | ○ | A5P.2601-BK |
| Dark Field | Dry Dark Field Condenser, Apply For 4x - 40x Objective | ○ | A5D.2610+BK |
| Immersion Dark Field Condenser, Apply For 100x Objective | ○ | A5D.2610-BKW |
| Phase Contrast | 5 Holes Phase Contrast Conenser, With Infinity Plan Phase Contrast
Objective 10x,20x,40x,100x, Centering Telescope 10x | ○ | A5C.2603-BS |
| LED Fluorescence | Newly Design 2025!
Ultra LED Inverted Fluorescent Microscope With
All-in-One Filter + 5W LED System
The LED Fluorescent Light Source And The Fluorescent Filter Are
Fixed as One Unit And Move Together, Switch Easily And Providing An
Ultra-high Brightness Fluorescent Light Source.
A16.2610-UL2 B,G China Fluorescent Filters
A16.2610-UL3 B,G,UV China Fluorescent Filters
A16.2610-UL4 B,G,U,UV China Fluorescent Filters | ● | A5F.2610-2
A5F.2610-3
A5F.2610-4 |
| Koehler Illumination | 5W-LED Illumination | ● | A56.2612-5WL |
| 12V/50W Halogen Lamp | ○ | A56.2613-12V50WL |
| 12V/100W Halogen Lamp | ○ | A56.2613-12V100WL |
| C-mount | 0.5x C-Mount, Focus Adjustable | ● | A55.2601-05 |
| 0.35x C-Mount, Focus Adjustable | ○ | A55.2601-35 |
| 0.75x C-Mount, Focus Adjustable | ○ | A55.2601-75 |
| 1.0x C-Mount, Focus Adjustable | ○ | A55.2601-10 |
| Filter | Forested Glass Filter | ● | A56.2616-RSN |
| Blue/ Green/ Yellow | ○ | A56.2616-RSB |
| Green Filter | ○ | A56.2616-RSG |
| Yellow Filter | ○ | A56.2616-RSY |
LCD Screen ECO
(Optional Only For LED Stand) | LCD Screen Optional For A12.2610 LED Stand, Function:
1,Show Customer Logo；
2,Show Objective Magnification；
3,Show & Remember Brightness For Each Objective；
4,Set ECO Timer；
5,Adjust Light Color Temperature 3500K--6000K. | ○ | A56.2661 |
